IFM EVC447 is a 0.4 m connection cable designed for dependable connectivity between industrial automation components. It features an angled M8 plug and straight M8 socket for convenient cable routing in machine installations. Its PUR cable, gold-plated contacts and high protection rating provide reliable industrial performance.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Flexible M8 Connection
EVC447 provides a reliable connection between compatible sensors and automation components. Its angled M8 plug helps improve cable routing in confined machine spaces. The straight M8 socket supports convenient component connection. Gold-plated contacts help ensure stable electrical performance.
Compact 0.4 m Cable
The 0.4 m cable length is suitable for short-distance machine connections. PUR construction provides flexibility and durability for industrial use. Its compact design helps maintain organized machine wiring. It is suitable for equipment-level automation applications.
High Environmental Protection
EVC447 provides IP65, IP67, IP68 and IP69K protection. FKM sealing helps protect the connector against moisture and contamination. The robust connection design supports resistance to vibration and shock. This makes it suitable for demanding industrial environments.
Suitable for Moving Machinery
The cable supports drag-chain applications and repeated movement. It is designed for more than 5 million bending cycles. The minimum bending radius is 10 times the cable diameter. This supports dependable performance in automated equipment.
0.4 m PUR cable
M8 angled plug
M8 straight socket
3 × 0.25 mm² conductors
Gold-plated contacts
AC/DC electrical design
50 V AC / 60 V DC operation
Halogen-free construction
Silicone-free
IP65 / IP67 / IP68 / IP69K protection
Drag-chain suitable
High bending-cycle capability
Industrial automation
Factory automation
Machine tools
Sensor and actuator connections
Automated production machinery
Robotic equipment
Industrial control systems
Compact machine installations
| Specification | Details |
|---|---|
| Product Code | EVC447 |
| Product Type | Connection Cable |
| Manufacturer | IFM |
| Order Code | VDOAF030MSS00,4H03STGF030MSS |
| Cable Length | 0.4 m |
| Cable Material | PUR |
| Cable Colour | Black |
| Cable Diameter | Approx. 3.7 mm |
| Conductor | 3 × 0.25 mm² |
| Plug | M8, angled |
| Socket | M8, straight |
| Electrical Design | AC/DC |
| Operating Voltage | 50 V AC / 60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Contacts | Gold-plated |
| Housing Material | TPU |
| Nut Material | Brass, nickel-plated |
| Sealing Material | FKM / Viton |
| Drag Chain Suitability | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Pack Quantity | 1 pc |
