IFM EVC446 is a 0.2 m connection cable designed for reliable industrial automation connections in compact machine installations. It features an angled M8 plug and straight M8 socket with gold-plated contacts. The PUR cable provides flexibility, durability and protection for demanding industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Angled Connection Design
EVC446 uses an angled M8 plug with a straight M8 socket to provide flexible connection routing. The angled connector can be useful where installation space is restricted. Gold-plated contacts support reliable electrical connectivity. It is suitable for industrial automation equipment.
Compact Cable Length
The 0.2 m cable length is designed for short-distance connections between closely positioned components. PUR construction provides flexibility and mechanical durability. Its compact design helps reduce excess cable in machine installations. It is suitable for sensor and actuator connections.
Reliable Industrial Protection
The cable provides IP65, IP67, IP68 and IP69K protection. FKM sealing helps protect the connection from dust and moisture. The connector construction provides resistance to vibration and shock. This supports reliable operation in industrial machinery.
Dynamic Performance
EVC446 is suitable for applications involving repeated cable movement. It supports drag-chain use and more than 5 million bending cycles. The minimum bending radius is 10 times the cable diameter. This makes it suitable for automated equipment.
0.2 m PUR cable
M8 angled plug
M8 straight socket
3 × 0.25 mm² conductors
Gold-plated contacts
AC/DC electrical design
50 V AC / 60 V DC operation
Halogen-free
Silicone-free
IP65 / IP67 / IP68 / IP69K protection
Compact installation design
Drag-chain suitable
Industrial automation
Factory automation
Machine tools
Sensor connections
Actuator connections
Compact machine wiring
Automated machinery
Robotic equipment
| Specification | Details |
|---|---|
| Product Code | EVC446 |
| Product Type | Connection Cable |
| Manufacturer | IFM |
| Order Code | VDOAF030MSS00,2H03STGF030MSS |
| Cable Length | 0.2 m |
| Cable Material | PUR |
| Cable Colour | Black |
| Cable Diameter | Approx. 3.7 mm |
| Conductor | 3 × 0.25 mm² |
| Plug | M8, angled |
| Socket | M8, straight |
| Electrical Design | AC/DC |
| Operating Voltage | 50 V AC / 60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Contacts | Gold-plated |
| Housing Material | TPU |
| Nut Material | Brass, nickel-plated |
| Sealing Material | FKM / Viton |
| Drag Chain Suitability | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Pack Quantity | 1 pc |
