IFM EVC443 is a 0.7 m M8 connection cable designed for reliable connections between industrial automation components. It features straight M8 plug and socket connectors with gold-plated contacts. The PUR cable provides flexibility, durability and reliable environmental protection for industrial applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Dependable Connectivity
EVC443 provides a stable connection between compatible sensors, actuators and automation equipment. Its straight M8 configuration supports simple system integration. Gold-plated contacts help maintain reliable electrical performance. It is suitable for industrial automation systems.
Practical 0.7 m Length
The 0.7 m cable is suitable for short machine connections where compact cable routing is required. Its PUR construction offers flexibility and mechanical durability. The cable can be conveniently routed around industrial equipment. It helps maintain a clean installation.
High Protection Rating
EVC443 is designed for IP65, IP67, IP68 and IP69K protection. FKM sealing helps protect the connector interface against moisture and contamination. The connector assembly is designed to withstand industrial vibration and shock. This supports reliable operation.
Dynamic Cable Performance
The cable supports drag-chain applications and repeated movement. It is designed for more than 5 million bending cycles. The minimum bending radius is 10 times the cable diameter. This makes it suitable for automated machinery.
0.7 m PUR cable
M8 straight plug
M8 straight socket
3 × 0.25 mm² conductors
Gold-plated contacts
AC/DC electrical design
50 V AC / 60 V DC operation
Halogen-free construction
Silicone-free cable
IP65 / IP67 / IP68 / IP69K protection
Drag-chain suitable
High bending-cycle performance
Factory automation
Industrial automation
Machine tools
Sensor and actuator connections
Automated production systems
Robotic machinery
Industrial control equipment
Machine wiring
| Specification | Details |
|---|---|
| Product Code | EVC443 |
| Product Type | Connection Cable |
| Manufacturer | IFM |
| Order Code | VDOGF030MSS00,7H03STGF030MSS |
| Cable Length | 0.7 m |
| Cable Material | PUR |
| Cable Colour | Black |
| Cable Diameter | Approx. 3.7 mm |
| Conductor | 3 × 0.25 mm² |
| Plug | M8, straight |
| Socket | M8, straight |
| Electrical Design | AC/DC |
| Operating Voltage | 50 V AC / 60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Contacts | Gold-plated |
| Housing Material | TPU |
| Nut Material | Brass, nickel-plated |
| Sealing Material | FKM / Viton |
| Drag Chain Suitability | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Pack Quantity | 1 pc |
