IFM EVC442 is a 0.5 m M8 connection cable designed for reliable industrial automation connectivity. It uses straight M8 plug and socket connectors with gold-plated contacts. Its PUR cable construction provides flexibility, durability and protection for sensors, actuators and automation equipment.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Reliable M8 Connection
EVC442 provides a secure connection between compatible automation components. The straight M8 connectors allow easy integration into industrial systems. Gold-plated contacts support dependable electrical signal transmission. The cable is suitable for factory and machine automation.
Flexible 0.5 m Cable
The 0.5 m length is ideal for short connections between closely positioned components. PUR construction provides flexibility and mechanical strength. The cable can be routed conveniently around machine components. Its compact design supports clean installation.
Industrial Environmental Protection
The cable provides IP65, IP67, IP68 and IP69K protection. FKM sealing supports reliable protection against dust and moisture. The connector design provides resistance to vibration and mechanical stress. It is suitable for demanding industrial environments.
Dynamic Applications
EVC442 is suitable for drag-chain installations and repeated movement. It supports more than 5 million bending cycles. The minimum bending radius is 10 times the cable diameter. This helps provide dependable performance in automated machinery.
0.5 m PUR cable
M8 straight plug
M8 straight socket
3 × 0.25 mm² conductors
Gold-plated contacts
50 V AC / 60 V DC operation
Halogen-free
Silicone-free
IP65 / IP67 / IP68 / IP69K protection
Drag-chain suitable
High bending-cycle capability
Industrial automation
Machine tools
Factory automation
Sensor connections
Actuator connections
Control equipment
Automated production machinery
Industrial wiring systems
| Specification | Details |
|---|---|
| Product Code | EVC442 |
| Product Type | Connection Cable |
| Manufacturer | IFM |
| Order Code | VDOGF030MSS00,5H03STGF030MSS |
| Cable Length | 0.5 m |
| Cable Material | PUR |
| Cable Colour | Black |
| Cable Diameter | Approx. 3.7 mm |
| Conductor | 3 × 0.25 mm² |
| Plug | M8, straight |
| Socket | M8, straight |
| Electrical Design | AC/DC |
| Operating Voltage | 50 V AC / 60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Contacts | Gold-plated |
| Housing Material | TPU |
| Nut Material | Brass, nickel-plated |
| Sealing Material | FKM / Viton |
| Drag Chain Suitability | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Pack Quantity | 1 pc |
