IFM EVC424 is a 40 m connecting cable with a 4-pin M8 straight socket designed for industrial automation applications. It features a PUR, halogen-free cable with gold-plated contacts and FKM sealing. The cable is suitable for machine tools, factory automation and demanding industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Extended Connection Capability
EVC424 provides a long 40 m connection solution for industrial automation installations. Its 4-pin M8 socket supports reliable connections with compatible automation components. Gold-plated contacts help maintain dependable electrical connectivity. The cable is suitable for extended machine and production-line layouts.
Durable PUR Cable
The 40 m PUR cable is designed for flexibility and mechanical durability. Its halogen-free construction is suitable for industrial installations. The cable is resistant to oils and coolants found around machine tools. The black outer sheath provides a practical industrial solution.
Industrial Protection
EVC424 provides IP65, IP67, IP68 and IP69K protection. FKM sealing helps protect the connector from environmental contamination. The robust connector construction supports reliable performance under vibration and mechanical stress. It is suitable for demanding factory environments.
Designed for Dynamic Applications
EVC424 supports drag-chain use and repeated cable movement. It is specified for more than 5 million bending cycles. The minimum bending radius is 10 times the cable diameter. This provides flexibility for automated machinery and moving equipment.
40 m PUR cable
4-pin M8 straight socket
A-coded connector
Gold-plated contacts
4 × 0.25 mm² conductors
Halogen-free cable
Silicone-free construction
IP65 / IP67 / IP68 / IP69K protection
Oil and coolant resistant
Drag-chain suitable
High bending-cycle capability
Industrial automation systems
Factory automation
Machine tools
Industrial sensor connections
Automated production machinery
Robotic systems
Control and monitoring equipment
Industrial cable installations
| Specification | Details |
|---|---|
| Product Code | EVC424 |
| Product Type | Connecting Cable with Socket |
| Manufacturer | IFM |
| Order Code | ADOGF040MSS0040H04 |
| Cable Length | 40 m |
| Cable Material | PUR |
| Cable Colour | Black |
| Cable Diameter | Ø3.7 mm |
| Conductor | 4 × 0.25 mm² |
| Socket | 1 × M8, straight |
| Coding | A |
| Contacts | 4, gold-plated |
| Housing Material | TPU |
| Nut Material | Nickel-plated brass |
| Sealing Material | FKM |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Drag Chain Suitability | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Weight | Approx. 856.5 g |
| Dimensions | 10 × 10 × 31 mm |
| Pack Quantity | 1 pc |
