IFM EVC277 is a 1 m M8 plug to M8 socket connection cable with a straight plug and angled socket. It is designed for reliable sensor and actuator connectivity in industrial automation systems. The PUR cable provides flexibility and durability, while gold-plated contacts support stable signal transmission. Its high IP protection and drag-chain suitability make it suitable for demanding machinery.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EVC277 provides a practical 1 m cable length for industrial machine installations. Its straight M8 plug and angled M8 socket allow convenient routing around equipment. The angled socket is useful in applications with restricted space. The connection design helps maintain clean and organized machine wiring.
The cable supports AC/DC applications with less than 50 V AC and less than 60 V DC. Gold-plated contacts help maintain dependable electrical performance. The 3 A current rating supports compatible sensor and actuator applications. The locking mechanism provides a secure connection during operation.
PUR cable construction provides flexibility and mechanical durability. TPU connector housing provides mechanical protection, while FKM sealing helps maintain reliable environmental protection. Brass nickel-plated locking components provide secure coupling. The cable is silicone-free and halogen-free.
The EVC277 provides IP65, IP67, IP68 and IP69K protection for demanding industrial conditions. It operates from -25°C to +90°C. Drag-chain suitability allows repeated movement in automated machinery. More than 5 million bending cycles provide long-term flexibility.
M8 plug to M8 socket
1 m PUR cable
3 × 0.25 mm² cable
Straight plug and angled socket
Gold-plated contacts
Silicone-free and halogen-free
<50 V AC / <60 V DC
3 A current rating
IP65 / IP67 / IP68 / IP69K
Drag-chain suitable
More than 5 million bending cycles
Industrial automation
Factory automation
Sensor connections
Actuator connections
Machine tools
Control and monitoring systems
Moving machinery
Production equipment
| Specification | Details |
|---|---|
| Product Model | EVC277 |
| Part Number | VDOAF030MSS0001H03STGF030MSS |
| Product Type | Connection Cable / Patchcord |
| Manufacturer | IFM |
| Connector 1 | M8 Plug |
| Connector 1 Design | Straight |
| Connector 2 | M8 Socket |
| Connector 2 Design | Angled |
| Coding | A-coded |
| Number of Contacts | 3 |
| Cable Length | 1 m |
| Cable Material | PUR |
| Cable Construction | 3 × 0.25 mm² |
| Cable Diameter | 3.7 mm |
| Electrical Design | AC/DC |
| Operating Voltage | <50 V AC / <60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Ambient Temperature | -25°C to +90°C |
| Moving Ambient Temperature | -25°C to +90°C |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Housing Material | TPU, orange |
| Sealing Material | FKM |
| Nut Material | Brass, nickel-plated |
| Contact Material | Gold-plated |
| Cable Colour | Black |
| Drag Chain Suitable | Yes |
| Minimum Bending Radius | 10 × cable diameter |
| Bending Cycles | >5 million |
| Travel Speed | Max. 3.3 m/s |
| Torsional Strain | ±180°/m |
| Dimensions | 10 × 10 × 36 mm |
| Weight | 39.9 g |
