IFM EVC271 is a 0.6 m M8 plug to M8 socket connection cable designed for reliable industrial automation connections. It uses a PUR cable with gold-plated contacts and straight connectors. The cable is silicone-free and halogen-free for demanding industrial applications. High IP protection and drag-chain suitability provide dependable performance in moving machinery.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EVC271 provides a convenient M8 plug-to-socket connection for industrial components. Its 0.6 m length provides additional routing flexibility compared with shorter patchcords. Straight connectors make installation simple. It is suitable for compact automation systems.
The cable supports AC/DC operation below 50 V AC and below 60 V DC. Gold-plated contacts help provide reliable electrical signal transmission. The 3 A current rating supports compatible sensor and actuator applications. The coupling mechanism provides secure connections.
The PUR cable provides flexibility and durability for industrial environments. TPU connector housings provide mechanical strength and FKM sealing protects the connection. Brass nickel-plated nuts provide secure mechanical coupling. The cable is resistant to demanding operating conditions.
The EVC271 provides IP65, IP67, IP68 and IP69K protection. It can operate from -25°C to +90°C. It is suitable for drag-chain applications and repeated movement. The cable supports more than 5 million bending cycles.
M8 plug to M8 socket
0.6 m PUR cable
3 × 0.25 mm² cable
Straight plug and straight socket
Gold-plated contacts
Silicone-free and halogen-free
<50 V AC / <60 V DC
3 A current rating
IP65 / IP67 / IP68 / IP69K
Drag-chain suitable
More than 5 million bending cycles
Industrial automation
Factory automation
Sensor and actuator connections
Machine tools
Control systems
Production equipment
Moving machinery
| Specification | Details |
|---|---|
| Product Model | EVC271 |
| Part Number | VDOGF040MSS00,6H03STGF030MSS |
| Product Type | Connection Cable / Patchcord |
| Manufacturer | IFM |
| Connector 1 | M8 Plug |
| Connector 1 Design | Straight |
| Connector 2 | M8 Socket |
| Connector 2 Design | Straight |
| Coding | A-coded |
| Number of Contacts | 3 |
| Cable Length | 0.6 m |
| Cable Material | PUR |
| Cable Construction | 3 × 0.25 mm² |
| Cable Diameter | 3.7 mm |
| Electrical Design | AC/DC |
| Operating Voltage | <50 V AC / <60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Ambient Temperature | -25°C to +90°C |
| Moving Ambient Temperature | -25°C to +90°C |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Housing Material | TPU, orange |
| Sealing Material | FKM |
| Nut Material | Brass, nickel-plated |
| Contact Material | Gold-plated |
| Cable Colour | Black |
| Drag Chain Suitable | Yes |
| Minimum Bending Radius | 10 × cable diameter |
| Bending Cycles | >5 million |
| Travel Speed | Max. 3.3 m/s |
| Torsional Strain | ±180°/m |
| Weight | 32.7 g |
