IFM EVC270 is a compact 0.3 m M8 plug to M8 socket connection cable for industrial automation applications. It features straight connectors on both ends for simple installation and direct cable routing. The PUR cable is flexible, durable and halogen-free with gold-plated contacts. Its high IP protection makes it suitable for demanding machine environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EVC270 is designed for short-distance connections between compatible M8 devices. Its 0.3 m cable length is ideal for compact machines and closely positioned components. Straight connectors provide simple installation and routing. It helps keep machine wiring neat and organized.
The cable provides dependable electrical connectivity for suitable AC/DC applications. Gold-plated contacts support stable signal transmission. The 3 A current rating is suitable for compatible industrial applications. The locking mechanism helps maintain secure connections during operation.
PUR cable construction provides flexibility and mechanical strength. TPU connector bodies provide robust mechanical protection, while FKM sealing helps protect the connection from environmental exposure. Nickel-plated brass locking components provide secure coupling. The cable is silicone-free and halogen-free.
The EVC270 provides IP65, IP67, IP68 and IP69K protection. It operates between -25°C and +90°C. Drag-chain suitability allows the cable to be used in moving machinery. It supports more than 5 million bending cycles.
M8 plug to M8 socket
0.3 m PUR cable
3 × 0.25 mm² cable
Straight plug and straight socket
Gold-plated contacts
Silicone-free and halogen-free
50 V AC / 60 V DC
3 A current rating
IP65 / IP67 / IP68 / IP69K
Drag-chain suitable
More than 5 million bending cycles
Industrial automation
Compact machinery
Machine tools
Sensor connections
Factory automation
Control equipment
Moving machinery
| Specification | Details |
|---|---|
| Product Model | EVC270 |
| Part Number | VDOGF040MSS00,3H03STGF030MSS |
| Product Type | Connection Cable / Patchcord |
| Manufacturer | IFM |
| Connector 1 | M8 Plug |
| Connector 1 Design | Straight |
| Connector 2 | M8 Socket |
| Connector 2 Design | Straight |
| Coding | A-coded |
| Number of Contacts | 3 |
| Cable Length | 0.3 m |
| Cable Material | PUR |
| Cable Construction | 3 × 0.25 mm² |
| Cable Diameter | 3.7 mm |
| Electrical Design | AC/DC |
| Operating Voltage | 50 V AC / 60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Ambient Temperature | -25°C to +90°C |
| Moving Ambient Temperature | -25°C to +90°C |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Housing Material | TPU, orange |
| Sealing Material | FKM |
| Nut Material | Brass, nickel-plated |
| Contact Material | Gold-plated |
| Cable Colour | Black |
| Drag Chain Suitable | Yes |
| Minimum Bending Radius | 10 × cable diameter |
| Bending Cycles | >5 million |
| Travel Speed | Max. 3.3 m/s |
| Torsional Strain | ±180°/m |
| Weight | 24 g |
