IFM EVC269 is a 5 m M8 plug to M8 socket connection cable designed for extended industrial sensor connections. It features a straight-to-straight connector arrangement with a flexible PUR cable and gold-plated contacts. The cable provides high protection against dust, water, oils and coolants. Its drag-chain suitability makes it appropriate for moving industrial machinery.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EVC269 provides a 5 m cable length for applications where sensors and control components are positioned farther apart. The M8 plug and M8 socket provide reliable connectivity between compatible devices. The straight connector arrangement simplifies cable routing. The extended length can reduce the need for additional cable extensions.
The cable supports AC/DC applications with an operating voltage below 50 V AC and below 60 V DC. Gold-plated contacts provide reliable signal transmission. A 3 A current rating supports suitable industrial sensor and actuator applications. The locking mechanism helps maintain a stable connection under vibration.
The EVC269 is protected to IP65, IP67, IP68 and IP69K standards. PUR cable construction provides flexibility and mechanical durability. FKM sealing helps maintain reliable protection at the connection points. The cable is suitable for industrial applications involving oils and coolants.
The cable is suitable for drag-chain applications and repeated machine movement. A minimum bending radius of 10 times the cable diameter helps protect the cable during movement. It supports more than 5 million bending cycles. This makes it suitable for automated production machinery.
M8 plug to M8 socket
5 m PUR cable
3 × 0.25 mm² cable
Straight plug and straight socket
Gold-plated contacts
Silicone-free and halogen-free
<50 V AC / <60 V DC
3 A current rating
IP65 / IP67 / IP68 / IP69K
Drag-chain suitable
Oil and coolant resistant
Industrial automation
Factory automation
Machine tools
Sensor and actuator connections
Production lines
Control systems
Moving machinery
| Specification | Details |
|---|---|
| Product Model | EVC269 |
| Part Number | VDOGF030MSS0005H03STGF030MSS |
| Product Type | Connection Cable / Patchcord |
| Manufacturer | IFM |
| Connector 1 | M8 Plug |
| Connector 1 Design | Straight |
| Connector 2 | M8 Socket |
| Connector 2 Design | Straight |
| Coding | A-coded |
| Number of Contacts | 3 |
| Cable Length | 5 m |
| Cable Material | PUR |
| Cable Construction | 3 × 0.25 mm² |
| Cable Diameter | 3.7 mm |
| Electrical Design | AC/DC |
| Operating Voltage | <50 V AC / <60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Ambient Temperature | -25°C to +90°C |
| Moving Ambient Temperature | -25°C to +90°C |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Housing Material | TPU, orange |
| Sealing Material | FKM |
| Nut Material | Brass, nickel-plated |
| Contact Material | Gold-plated |
| Cable Colour | Black |
| Drag Chain Suitable | Yes |
| Minimum Bending Radius | 10 × cable diameter |
| Bending Cycles | >5 million |
| Travel Speed | Max. 3.3 m/s |
| Torsional Strain | ±180°/m |
