IFM EVC268 is a 2 m M8 plug to M8 socket connection cable designed for industrial automation applications. It features straight connectors, a flexible PUR cable and gold-plated contacts for dependable electrical connectivity. The cable is silicone-free and halogen-free for demanding industrial environments. Its high IP protection and drag-chain suitability support reliable long-term operation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EVC268 provides a secure connection between compatible M8 sensors and automation components. Its straight plug and socket configuration makes installation and cable routing simple. Gold-plated contacts help maintain stable electrical signal transmission. The secure locking mechanism helps prevent accidental disconnection.
The cable is manufactured with flexible PUR insulation and robust TPU connector bodies. FKM sealing provides additional protection against moisture and environmental exposure. Brass nickel-plated locking components provide secure mechanical coupling. The construction is suitable for industrial machinery and factory automation.
The EVC268 provides IP65, IP67, IP68 and IP69K protection for demanding industrial conditions. It can operate from -25°C to +90°C. The cable is designed to withstand exposure to dust, water, oils and coolants. Its robust construction supports dependable operation in harsh environments.
The cable is suitable for drag-chain applications where repeated movement is required. It supports a minimum bending radius of 10 times the cable diameter. More than 5 million bending cycles are supported. Torsional strain capability of ±180°/m helps improve reliability during machine movement.
M8 plug to M8 socket
2 m PUR cable
3 × 0.25 mm² cable
Straight plug and straight socket
Gold-plated contacts
Silicone-free and halogen-free
<50 V AC / <60 V DC
3 A current rating
IP65 / IP67 / IP68 / IP69K protection
Drag-chain suitable
More than 5 million bending cycles
Industrial automation systems
Factory automation
Sensor connections
Machine tools
Control and monitoring equipment
Production machinery
Moving machine applications
| Specification | Details |
|---|---|
| Product Model | EVC268 |
| Part Number | VDOGF030MSS0002H03STGF030MSS |
| Product Type | Connection Cable / Patchcord |
| Manufacturer | IFM |
| Connector 1 | M8 Plug |
| Connector 1 Design | Straight |
| Connector 2 | M8 Socket |
| Connector 2 Design | Straight |
| Coding | A-coded |
| Number of Contacts | 3 |
| Cable Length | 2 m |
| Cable Material | PUR |
| Cable Construction | 3 × 0.25 mm² |
| Cable Diameter | 3.7 mm |
| Electrical Design | AC/DC |
| Operating Voltage | <50 V AC / <60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Ambient Temperature | -25°C to +90°C |
| Moving Ambient Temperature | -25°C to +90°C |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Housing Material | TPU, orange |
| Sealing Material | FKM |
| Nut Material | Brass, nickel-plated |
| Contact Material | Gold-plated |
| Cable Colour | Black |
| Drag Chain Suitable | Yes |
| Minimum Bending Radius | 10 × cable diameter |
| Bending Cycles | >5 million |
| Travel Speed | Max. 3.3 m/s |
| Torsional Strain | ±180°/m |
| Tightening Torque | 0.3–0.5 Nm |
| Weight | 57.6 g |
