IFM EVC267 is a 1 m M8 plug to M8 socket connection cable designed for reliable industrial automation connectivity. It features straight connectors at both ends for simple installation and cable routing. The PUR cable is halogen-free and uses gold-plated contacts for reliable signal transmission. Its IP65, IP67, IP68 and IP69K protection makes it suitable for harsh industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EVC267 provides a 1 m cable length suitable for common industrial machine installations. Its M8 plug-to-socket configuration provides secure connectivity between compatible devices. Straight connectors simplify installation and routing. It is suitable for sensor, actuator and automation connections.
The cable supports less than 50 V AC and less than 60 V DC. Gold-plated contacts help provide stable electrical signal transmission. The 3 A current rating supports compatible industrial applications. The locking mechanism provides a secure connection during machine operation.
PUR cable construction provides flexibility and durability. TPU connector housings provide mechanical protection, while FKM sealing helps protect against environmental exposure. The cable is free from silicone and halogens. Nickel-plated brass locking components provide secure coupling.
The EVC267 provides IP65, IP67, IP68 and IP69K protection. It operates between -25°C and 90°C. Drag-chain suitability makes it appropriate for moving applications. The cable supports more than 5 million bending cycles and ±180°/m torsional strain.
M8 plug to M8 socket
1 m PUR cable
3 × 0.25 mm² cable
Straight plug and straight socket
Gold-plated contacts
Less than 50 V AC / 60 V DC
3 A current rating
IP65 / IP67 / IP68 / IP69K protection
Drag-chain suitable
More than 5 million bending cycles
Industrial automation
Factory automation
Machine tools
Sensor connections
Actuator connections
Control and monitoring systems
Moving machinery
Production equipment
| Specification | Details |
|---|---|
| Product Model | EVC267 |
| Part Number | VDOGF030MSS0001H03STGF030MSS |
| Product Type | Connection Cable / Patchcord |
| Manufacturer | IFM |
| Connector 1 | M8 Plug |
| Connector 1 Design | Straight |
| Connector 2 | M8 Socket |
| Connector 2 Design | Straight |
| Coding | A-coded |
| Cable Length | 1 m |
| Cable Material | PUR |
| Cable Construction | 3 × 0.25 mm² |
| Cable Diameter | 3.7 mm |
| Electrical Design | AC/DC |
| Operating Voltage | <50 V AC / <60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Ambient Temperature | -25°C to +90°C |
| cULus Temperature | Max. 80°C |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Housing Material | TPU / Urethane |
| Sealing Material | FKM |
| Nut Material | Brass, nickel-plated |
| Contact Material | Gold-plated |
| Cable Colour | Black |
| Drag Chain Suitable | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Weight | 40.7 g |
