IFM EVC266 is a 0.6 m M8 plug to M8 socket connection cable designed for industrial automation systems. Both connectors feature a straight design for simple installation and routing. The cable uses flexible PUR construction with gold-plated contacts. High IP protection and drag-chain suitability provide reliable performance in industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EVC266 provides an M8 plug-to-socket connection for compatible industrial components. Its straight-to-straight design makes installation straightforward. The 0.6 m cable length provides convenient connectivity between nearby devices. It is suitable for compact automation equipment.
The cable supports less than 50 V AC and less than 60 V DC. Gold-plated contacts support dependable signal transmission. Its 3 A current rating provides suitable electrical capacity for compatible applications. The locking system helps maintain secure connections.
The EVC266 uses PUR cable and robust TPU connector housing. FKM sealing provides additional protection against environmental conditions. The cable is silicone-free and halogen-free. Nickel-plated brass locking components provide secure mechanical coupling.
The EVC266 provides IP65, IP67, IP68 and IP69K protection. It operates from -25°C to 90°C. The cable is suitable for drag-chain applications. It supports more than 5 million bending cycles for repeated machine movement.
M8 plug to M8 socket
0.6 m PUR cable
3 × 0.25 mm² cable
Straight plug and straight socket
Gold-plated contacts
Less than 50 V AC / 60 V DC
3 A current rating
IP65 / IP67 / IP68 / IP69K
Drag-chain suitable
More than 5 million bending cycles
Industrial automation
Factory automation
Machine tools
Sensor and actuator connections
Control systems
Production machinery
Moving equipment
| Specification | Details |
|---|---|
| Product Model | EVC266 |
| Part Number | VDOGF030MSS00,6H03STGF030MSS |
| Product Type | Connection Cable / Patchcord |
| Manufacturer | IFM |
| Connector 1 | M8 Plug |
| Connector 1 Design | Straight |
| Connector 2 | M8 Socket |
| Connector 2 Design | Straight |
| Coding | A-coded |
| Cable Length | 0.6 m |
| Cable Material | PUR |
| Cable Construction | 3 × 0.25 mm² |
| Cable Diameter | 3.7 mm |
| Electrical Design | AC/DC |
| Operating Voltage | <50 V AC / <60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Ambient Temperature | -25°C to +90°C |
| cULus Temperature | Max. 80°C |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Housing Material | TPU / Urethane |
| Sealing Material | FKM |
| Nut Material | Brass, nickel-plated |
| Contact Material | Gold-plated |
| Cable Colour | Black |
| Drag Chain Suitable | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Weight | 31.9 g |
