IFM EVC265 is a compact 0.3 m M8 plug to M8 socket connection cable for industrial automation applications. It features straight connectors on both ends for simple and direct installation. The PUR cable provides flexibility, while gold-plated contacts support reliable electrical connectivity. Its high IP protection and drag-chain suitability make it suitable for demanding machinery.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EVC265 features an M8 plug and M8 socket with straight connector design. This configuration provides simple cable routing and installation. The compact 0.3 m length is suitable for short-distance connections. It is useful for compact automation systems and machinery.
Gold-plated contacts help maintain stable electrical connectivity. The cable supports less than 50 V AC and less than 60 V DC. Its 3 A current rating is suitable for compatible industrial applications. The secure coupling mechanism helps prevent accidental disconnection.
The EVC265 uses a PUR cable with TPU connector housing. FKM sealing provides additional protection against environmental exposure. The cable is free from silicone and halogens. The robust design is suitable for industrial automation environments.
The cable is suitable for drag-chain applications and repeated movement. It supports more than 5 million bending cycles. The minimum bending radius is 10 times the cable diameter. This makes it suitable for moving machinery and automated production systems.
M8 plug to M8 socket
0.3 m PUR cable
3 × 0.25 mm² cable
Straight plug and straight socket
Gold-plated contacts
Less than 50 V AC / 60 V DC
3 A current rating
IP65 / IP67 / IP68 / IP69K
Drag-chain suitable
More than 5 million bending cycles
Industrial automation
Machine tools
Sensor connections
Factory automation
Control systems
Moving machinery
Production equipment
| Specification | Details |
|---|---|
| Product Model | EVC265 |
| Part Number | VDOGF030MSS00,3H03STGF030MSS |
| Product Type | Connection Cable / Patchcord |
| Manufacturer | IFM |
| Connector 1 | M8 Plug |
| Connector 1 Design | Straight |
| Connector 2 | M8 Socket |
| Connector 2 Design | Straight |
| Coding | A-coded |
| Cable Length | 0.3 m |
| Cable Material | PUR |
| Cable Construction | 3 × 0.25 mm² |
| Cable Diameter | 3.7 mm |
| Electrical Design | AC/DC |
| Operating Voltage | <50 V AC / <60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Ambient Temperature | -25°C to +90°C |
| cULus Temperature | Max. 80°C |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Housing Material | TPU / Urethane |
| Sealing Material | FKM |
| Nut Material | Brass, nickel-plated |
| Contact Material | Gold-plated |
| Cable Colour | Black |
| Drag Chain Suitable | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Weight | 26.6 g |
