IFM EVC264 is a 5 m M8 plug to M8 socket connection cable designed for industrial automation and machine applications. Its straight plug and angled socket configuration provides flexible installation and routing. The PUR cable is halogen-free and uses gold-plated contacts. High IP protection and drag-chain suitability support reliable operation in demanding environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EVC264 provides a 5 m cable length for applications requiring extended connection distances. It connects compatible M8 industrial components securely. The angled socket helps simplify routing around machinery. The extended length reduces the need for additional cable extensions.
The cable supports AC/DC applications with less than 50 V AC and less than 60 V DC. Gold-plated contacts help provide stable signal transmission. The 3 A current rating supports suitable industrial applications. The locking system helps maintain secure connections.
PUR cable construction provides flexibility and mechanical strength. TPU housing and FKM sealing provide additional environmental protection. Nickel-plated brass locking components ensure secure coupling. The cable is designed for demanding industrial automation environments.
The EVC264 offers IP65, IP67, IP68 and IP69K protection. It operates from -25°C to 90°C. Drag-chain suitability makes it suitable for moving machine applications. The cable supports repeated bending and mechanical movement.
M8 plug to M8 socket
5 m PUR cable
3 × 0.25 mm² cable
Straight plug and angled socket
Gold-plated contacts
Less than 50 V AC / 60 V DC
3 A current rating
IP65 / IP67 / IP68 / IP69K
Drag-chain suitable
Oil and coolant resistant
Industrial automation
Machine tools
Factory automation
Sensor connections
Actuator connections
Production machinery
Moving machine systems
| Specification | Details |
|---|---|
| Product Model | EVC264 |
| Part Number | VDOAF040MSS0005H03STGF030MSS |
| Product Type | Connection Cable / Patchcord |
| Manufacturer | IFM |
| Connector 1 | M8 Plug |
| Connector 1 Design | Straight |
| Connector 2 | M8 Socket |
| Connector 2 Design | Angled |
| Coding | A-coded |
| Cable Length | 5 m |
| Cable Material | PUR |
| Cable Construction | 3 × 0.25 mm² |
| Cable Diameter | 3.7 mm |
| Electrical Design | AC/DC |
| Operating Voltage | <50 V AC / <60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Ambient Temperature | -25°C to +90°C |
| cULus Temperature | Max. 80°C |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Housing Material | TPU / Urethane |
| Sealing Material | FKM |
| Nut Material | Brass, nickel-plated |
| Contact Material | Gold-plated |
| Cable Colour | Black |
| Drag Chain Suitable | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
