IFM EVC263 is a 2 m M8 plug to M8 socket connection cable designed for reliable industrial connectivity. It features a straight plug and angled socket for convenient installation and routing. The 3-core PUR cable provides flexibility and durability for automation applications. Gold-plated contacts and IP65/IP67/IP68/IP69K protection support dependable operation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The 2 m cable length provides additional flexibility when connecting sensors and control components. The M8-to-M8 configuration supports compatible industrial devices. The angled socket can be useful in restricted installation spaces. The cable provides a clean and practical connection solution.
The EVC263 supports AC/DC applications with less than 50 V AC and less than 60 V DC. It provides a 3 A current rating. Gold-plated contacts support reliable electrical signal transmission. The locking arrangement helps maintain a secure connection during machine operation.
The cable is constructed from flexible PUR material. TPU connector housing and FKM sealing provide protection against environmental exposure. Brass nickel-plated locking components provide secure mechanical coupling. The cable is silicone-free and halogen-free.
The EVC263 offers IP65, IP67, IP68 and IP69K protection. It can operate from -25°C to 90°C. Drag-chain suitability makes it appropriate for moving applications. Its construction supports more than 5 million bending cycles.
M8 plug to M8 socket
2 m PUR cable
3 × 0.25 mm² cable
Straight plug and angled socket
Gold-plated contacts
Less than 50 V AC / 60 V DC
3 A current rating
IP65 / IP67 / IP68 / IP69K protection
Drag-chain suitable
More than 5 million bending cycles
Industrial automation
Factory automation
Machine tools
Sensor connections
Actuator connections
Control systems
Moving machinery
| Specification | Details |
|---|---|
| Product Model | EVC263 |
| Part Number | VDOAF040MSS0002H03STGF030MSS |
| Product Type | Connection Cable / Patchcord |
| Manufacturer | IFM |
| Connector 1 | M8 Plug |
| Connector 1 Design | Straight |
| Connector 2 | M8 Socket |
| Connector 2 Design | Angled |
| Coding | A-coded |
| Cable Length | 2 m |
| Cable Material | PUR |
| Cable Construction | 3 × 0.25 mm² |
| Cable Diameter | 3.7 mm |
| Electrical Design | AC/DC |
| Operating Voltage | <50 V AC / <60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Ambient Temperature | -25°C to +90°C |
| cULus Temperature | Max. 80°C |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Housing Material | TPU / Urethane |
| Sealing Material | FKM |
| Nut Material | Brass, nickel-plated |
| Contact Material | Gold-plated |
| Cable Colour | Black |
| Drag Chain Suitable | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Weight | 57.5 g |
