IFM EVC262 is a 1 m M8 plug to M8 socket connection cable designed for industrial automation systems. It features a straight plug and angled socket configuration for convenient installation. The PUR cable is halogen-free and includes gold-plated contacts. High IP protection and drag-chain suitability make it suitable for demanding industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EVC262 provides a 1 m connection length suitable for common industrial machine installations. Its M8 plug and M8 socket configuration provides reliable device connectivity. The angled socket can simplify cable routing around machine components. The cable is suitable for compact and standard automation setups.
The cable supports less than 50 V AC and less than 60 V DC. Its 3 A current rating provides suitable capacity for compatible applications. Gold-plated contacts support dependable signal transmission. The secure locking mechanism helps maintain stable connections during operation.
PUR cable construction provides flexibility and mechanical durability. TPU connector housing and FKM sealing provide protection against environmental conditions. The cable is free from silicone and halogens. Brass nickel-plated locking components provide secure mechanical coupling.
The EVC262 provides IP65, IP67, IP68 and IP69K protection. It operates from -25°C to 90°C. Drag-chain suitability makes it appropriate for moving machinery. The cable supports more than 5 million bending cycles.
M8 plug to M8 socket
1 m PUR cable
3 × 0.25 mm² cable
Straight plug and angled socket
Gold-plated contacts
Less than 50 V AC / 60 V DC
3 A current rating
IP65 / IP67 / IP68 / IP69K protection
Drag-chain suitable
Silicone-free and halogen-free
Industrial automation
Sensor and actuator connections
Machine tools
Factory automation
Production machinery
Control systems
Moving equipment
| Specification | Details |
|---|---|
| Product Model | EVC262 |
| Part Number | VDOAF040MSS0001H03STGF030MSS |
| Product Type | Connection Cable / Patchcord |
| Manufacturer | IFM |
| Connector 1 | M8 Plug |
| Connector 1 Design | Straight |
| Connector 2 | M8 Socket |
| Connector 2 Design | Angled |
| Coding | A-coded |
| Cable Length | 1 m |
| Cable Material | PUR |
| Cable Construction | 3 × 0.25 mm² |
| Cable Diameter | 3.7 mm |
| Electrical Design | AC/DC |
| Operating Voltage | <50 V AC / <60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Ambient Temperature | -25°C to +90°C |
| cULus Temperature | Max. 80°C |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Housing Material | TPU / Urethane |
| Sealing Material | FKM |
| Nut Material | Brass, nickel-plated |
| Contact Material | Gold-plated |
| Cable Colour | Black |
| Drag Chain Suitable | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Bending Cycles | >5 million |
| Weight | 40.1 g |
