IFM EVC255 is a compact 0.3 m M8-to-M12 connection cable for industrial sensor and actuator connectivity. It uses a three-core PUR cable with gold-plated contacts. The cable supports AC/DC applications and provides a high IP protection rating. Its compact design is suitable for short-distance connections inside machinery.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Compact Connection Solution
The EVC255 has a short 0.3 m cable length for compact machine installations. It connects an M8 plug to an M12 socket. The straight connector arrangement supports simple routing. It is useful where limited cable length is preferred.
Reliable Electrical Connection
The cable supports AC/DC operation with up to 3 A current rating. Its three-core PUR cable provides dependable electrical connectivity. Gold-plated contacts help maintain stable signal transmission. The robust connectors support reliable operation in industrial systems.
Durable Industrial Performance
The EVC255 provides IP65, IP67, IP68 and IP69K protection. It is suitable for temperatures from -25 to 90°C. The cable is silicone-free and halogen-free. Its drag-chain suitability supports applications involving repeated movement.
M8 plug / M12 socket
0.3 m PUR cable
3-core construction
AC/DC electrical design
50 V AC / 60 V DC
3 A current rating
Gold-plated contacts
IP65 / IP67 / IP68 / IP69K
Drag-chain suitable
Industrial automation
Compact machine wiring
Sensor and actuator connections
Control systems
Machine tools
Factory automation
| Specification | Details |
|---|---|
| Product Model | EVC255 |
| Manufacturer | IFM |
| Part Number | VDOGH030MSS00,3H03STGF030MSS |
| Product Type | Connection cable / Patchcord |
| Connector | M8 plug / M12 socket |
| Connector Design | Straight / straight |
| Number of Pins | 3 |
| Cable Length | 0.3 m |
| Cable Material | PUR |
| Cable Size | 3 × 0.34 mm² |
| Cable Diameter | Approx. 4.9 mm |
| Electrical Design | AC/DC |
| Operating Voltage | <50 V AC / <60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Ambient Temperature | -25 to 90°C |
| Protection Rating | IP65 / IP67 / IP68 / IP69K |
| Housing Material | TPU |
| Sealing Material | FKM |
| Contact Material | Gold-plated |
| Drag Chain Suitable | Yes |
| Weight | Approx. 37.8 g |
