EVC246 is a 0.6 m M8-to-M12 industrial connection cable for reliable sensor and automation connectivity. It uses a 3-pole straight M8 plug and an angled 5-pole M12 socket. The PUR cable offers flexibility and mechanical durability. Its high protection makes it suitable for demanding industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
EVC246 provides a reliable connection between compatible M8 and M12 industrial devices. The angled M12 socket helps simplify routing around machine components. Gold-plated contacts support stable signal transmission. Secure locking helps maintain the connection.
The 0.6 m length is suitable for short-to-medium machine connections. It provides more routing flexibility than the 0.3 m version. PUR construction supports flexible installation. The cable helps reduce excess wiring.
The cable is made from PUR and is halogen-free. It is also silicone-free for industrial applications. Connector materials support vibration and shock resistance. The design is suitable for continuous machine operation.
EVC246 is resistant to oils and coolants. IP65/IP67/IP68/IP69K protection supports demanding industrial conditions. Reliable sealing protects the connection from environmental contamination. Drag-chain suitability supports moving applications.
0.6 m cable length
M8 straight plug
M12 angled socket
3-pole M8
5-pole M12
PUR cable
Halogen-free
Silicone-free
Gold-plated contacts
Oil resistant
Coolant resistant
IP65 / IP67 / IP68 / IP69K
Drag-chain suitable
Industrial sensors
Factory automation
Machine tools
Actuator systems
Production machinery
Conveyor equipment
Sensor networks
Automation systems
| Specification | Details |
|---|---|
| Product Type | Connection Cable |
| Model | VDOAH030MSS00,6H03STGF030MSS |
| Cable Length | 0.6 m |
| Connector A | M8 Plug, Straight |
| M8 Contacts | 3 |
| Connector B | M12 Socket, Angled |
| M12 Contacts | 5 |
| Coding | A |
| Cable Material | PUR |
| Cable Size | 3 × 0.34 mm² |
| Cable Diameter | Approx. 4.3 mm |
| Cable Colour | Black |
| Contact Finish | Gold-plated |
| Housing | TPU |
| Nut | Brass, nickel-plated |
| Sealing | FKM |
| Operating Voltage | <50 V AC / <60 V DC |
| Protection Class | III |
| Current Rating | 3 A |
| Temperature | -25°C to +90°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Drag Chain | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Pack Quantity | 1 pc |
