EVC230 is a compact 0.3 m M12-to-M8 connection cable designed for industrial automation and sensor applications. It provides a 3-pole M12 connector and 3-pole M8 socket configuration. The PUR halogen-free cable provides reliable and flexible industrial connectivity. Its compact design is suitable for short machine-level connections.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
EVC230 provides a direct connection between compatible 3-pole M12 and M8 devices. The standardized interface supports industrial sensor connectivity. Secure locking helps maintain a reliable connection. It is suitable for compact automation systems.
The 0.3 m length is suitable for closely positioned machine components. It minimizes excess wiring around sensors. PUR construction provides flexibility and mechanical durability. The cable helps create clean machine-level installations.
The cable uses black PUR material with a halogen-free construction. Gold-plated contacts provide reliable electrical transmission. Robust connector materials support continuous industrial use. The cable is designed for demanding automation environments.
High IP protection supports operation in industrial environments involving moisture, oils and coolants. The sealed connector construction helps protect electrical interfaces. The cable is suitable for machine tools and factory automation. Its robust design supports reliable long-term operation.
0.3 m cable length
M12 3-pole connector
M8 3-pole socket
PUR cable
Halogen-free
Gold-plated contacts
Oil and coolant resistant
IP67 / IP68 / IP69K
Compact design
Reliable signal transmission
Secure locking
Industrial durability
Industrial sensors
Factory automation
Machine tools
Compact machinery
Actuator connections
Control equipment
Production systems
Sensor networks
| Specification | Details |
|---|---|
| Product Type | Connection Cable |
| Model | VDOAF030MSS00,3H03STGH030MSS |
| Cable Length | 0.3 m |
| Connector A | M12 Plug |
| Connector B | M8 Socket |
| M12 Contacts | 3 |
| M8 Contacts | 3 |
| Cable Material | PUR |
| Cable Construction | 3 × 0.34 mm² |
| Cable Diameter | Approx. 4.9 mm |
| Cable Colour | Black |
| Cable Type | Halogen-free |
| M12 Voltage | 250 V AC / 300 V DC |
| M8 Voltage | 50 V AC / 60 V DC |
| Current Rating | 3 A |
| Operating Temperature | -25°C to +90°C |
| Protection | IP67 / IP68 / IP69K |
| Housing | TPU |
| Locking | CuZn / nickel-plated |
| Sealing | FKM |
| M8 Torque | 0.3–0.5 Nm |
| M12 Torque | 0.6–1.5 Nm |
| Application | Industrial |
| Pack Quantity | 1 pc |
