EVC229 is a 5 m M12-to-M8 industrial connection cable with integrated LED indication. It is designed for extended sensor and automation connections where visual status monitoring is useful. The PUR halogen-free cable provides flexibility and durability. High IP protection supports reliable operation in demanding industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
EVC229 combines long-distance connectivity with integrated LED status indication. The LED helps operators identify operating conditions quickly. This reduces the need for separate diagnostic equipment. It is suitable for distributed industrial sensor systems.
The 5 m cable provides extended routing across larger machine layouts. It can connect sensors and control equipment positioned farther apart. PUR construction supports flexible industrial routing. The extended length helps reduce additional cable extensions.
The cable uses a 3-pole M12 connector and 4-pole M8 socket. Gold-plated contacts support reliable electrical transmission. Secure locking components maintain the connection during machine operation. The configuration is suitable for compatible industrial automation devices.
The cable is designed for demanding industrial conditions. High IP protection supports resistance to dust and moisture. Oil and coolant resistance supports machine-tool applications. The robust PUR cable is suitable for continuous industrial use.
5 m cable length
M12 3-pole connector
M8 4-pole socket
LED status indication
10–36 V DC LED supply
PUR cable
Halogen-free
Gold-plated contacts
IP67 / IP68 / IP69K
Oil and coolant resistant
Extended machine routing
Visual diagnostics
Factory automation
Industrial sensor networks
Machine tools
Production systems
Sensor monitoring
Control equipment
Conveyor systems
Automation diagnostics
| Specification | Details |
|---|---|
| Product Type | Connection Cable with LED |
| Model | VDOAF032MSS0005H03STGH030MSS |
| Cable Length | 5 m |
| Connector A | M12 Plug |
| Connector B | M8 Socket |
| M12 Contacts | 3 |
| M8 Contacts | 4 |
| LED | Yes |
| LED Supply | 10–36 V DC |
| Cable Material | PUR |
| Cable Size | 3 × 0.34 mm² |
| Cable Diameter | Approx. 4.9 mm |
| Cable Colour | Black |
| Cable Type | Halogen-free |
| M12 Voltage | 250 V AC / 300 V DC |
| M8 Voltage | 50 V AC / 60 V DC |
| Current Rating | 3 A |
| Temperature | -25°C to +90°C |
| Protection | IP67 / IP68 / IP69K |
| Housing | TPU |
| Locking | CuZn / nickel-plated |
| Sealing | FKM |
| M8 Torque | 0.3–0.5 Nm |
| M12 Torque | 0.6–1.5 Nm |
| Application | Industrial |
| Pack Quantity | 1 pc |
