EVC228 is a 2 m M12-to-M8 connection cable with integrated LED indication for industrial automation. Its 3-pole M12 and 4-pole M8 configuration provides reliable connectivity between compatible devices. The PUR halogen-free cable supports durable operation in industrial environments. LED indication provides convenient visual status monitoring at the connection point.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The integrated LED helps provide immediate visual information about operating status. This can simplify maintenance and fault identification. Operators can inspect connection conditions directly at the cable. It is useful for distributed sensor installations.
The 2 m cable provides additional flexibility for machine wiring. It can connect components positioned farther apart without an extension. PUR construction provides flexibility and durability. The cable supports organized industrial cable routing.
The M12-to-M8 connector arrangement supports compatible automation devices. Gold-plated contacts provide dependable signal transmission. Secure locking helps maintain stable connections. The 3-pole and 4-pole interfaces support industrial sensor connectivity.
The cable is designed for industrial environments exposed to moisture, oils and coolants. High IP protection supports reliable operation. The PUR jacket provides mechanical durability. It is suitable for factory automation and machine tools.
2 m cable length
M12 3-pole connector
M8 4-pole socket
LED indication
10–36 V DC LED supply
PUR cable
Halogen-free
Gold-plated contacts
IP67 / IP68 / IP69K
Oil and coolant resistant
Visual diagnostics
Longer routing capability
Industrial sensors
Factory automation
Machine tools
Sensor monitoring
Production machinery
Control equipment
Actuator systems
Automation diagnostics
| Specification | Details |
|---|---|
| Product Type | Connection Cable with LED |
| Model | VDOAF032MSS0002H03STGH030MSS |
| Cable Length | 2 m |
| Connector A | M12 Plug |
| Connector B | M8 Socket |
| M12 Contacts | 3 |
| M8 Contacts | 4 |
| LED | Yes |
| LED Supply | 10–36 V DC |
| Cable Material | PUR |
| Cable Size | 3 × 0.34 mm² |
| Cable Diameter | Approx. 4.9 mm |
| Cable Colour | Black |
| Cable Type | Halogen-free |
| M12 Voltage | 250 V AC / 300 V DC |
| M8 Voltage | 50 V AC / 60 V DC |
| Current Rating | 3 A |
| Temperature | -25°C to +90°C |
| Protection | IP67 / IP68 / IP69K |
| Housing | TPU |
| Locking | CuZn / nickel-plated |
| Sealing | FKM |
| M8 Torque | 0.3–0.5 Nm |
| M12 Torque | 0.6–1.5 Nm |
| Application | Industrial |
| Pack Quantity | 1 pc |
