EVC227 is a 1 m M12-to-M8 connection cable with integrated LED indication for industrial automation applications. It combines a 3-pole M12 connector with a 4-pole M8 socket. The PUR halogen-free cable provides durable industrial connectivity. Visual LED indication makes equipment status easier to identify during operation and maintenance.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The LED indicator provides quick visual feedback at the connection point. This helps operators identify operating conditions without additional diagnostic equipment. It can reduce troubleshooting time. The feature is especially useful in distributed automation systems.
The 1 m length provides practical routing between sensors and nearby control components. The M12-to-M8 configuration supports compatible automation devices. Secure connectors provide reliable coupling. Gold-plated contacts support stable signal transmission.
The cable uses PUR material for flexibility and durability. Its halogen-free design supports industrial applications. The cable withstands demanding machine conditions. It is suitable for continuous automation operation.
High IP protection helps protect the connection from dust and moisture. Oil and coolant resistance supports machine-tool environments. Robust connector construction supports vibration and mechanical stress. The cable is suitable for demanding production equipment.
1 m cable length
M12 3-pole connector
M8 4-pole socket
Integrated LED
10–36 V DC LED supply
PUR cable
Halogen-free
Gold-plated contacts
IP67 / IP68 / IP69K
Oil and coolant resistant
Easy diagnostics
Reliable industrial connection
Sensor monitoring
Factory automation
Machine tools
Industrial sensors
Production lines
Control equipment
Automation panels
Machine diagnostics
| Specification | Details |
|---|---|
| Product Type | Connection Cable with LED |
| Model | VDOAF032MSS0001H03STGH030MSS |
| Cable Length | 1 m |
| Connector A | M12 Plug |
| Connector B | M8 Socket |
| M12 Contacts | 3 |
| M8 Contacts | 4 |
| LED | Yes |
| LED Supply | 10–36 V DC |
| Cable Material | PUR |
| Cable Size | 3 × 0.34 mm² |
| Cable Diameter | Approx. 4.9 mm |
| Cable Colour | Black |
| Cable Type | Halogen-free |
| M12 Voltage | 250 V AC / 300 V DC |
| M8 Voltage | 50 V AC / 60 V DC |
| Current Rating | 3 A |
| Temperature | -25°C to +90°C |
| Protection | IP67 / IP68 / IP69K |
| Housing | TPU |
| Locking | CuZn / nickel-plated |
| Sealing | FKM |
| M8 Torque | 0.3–0.5 Nm |
| M12 Torque | 0.6–1.5 Nm |
| Application | Industrial |
| Pack Quantity | 1 pc |
