EVC226 is a 0.6 m M12-to-M8 connection cable with LED indication for industrial automation systems. It provides a compact 3-pole M12 to 4-pole M8 connection. The LED indicator offers convenient visual status monitoring. PUR cable construction and high IP protection support reliable industrial operation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The integrated LED provides a convenient visual indication of operating status. It allows technicians to check connection conditions without additional equipment. This helps simplify troubleshooting. The feature is useful in sensor and automation installations.
The 0.6 m cable provides a practical connection between nearby components. Its compact length reduces unnecessary wiring. PUR construction provides flexibility for machine routing. The cable works well in space-constrained installations.
The M12 and M8 connectors provide a secure industrial interface. Gold-plated contacts support dependable signal transmission. The 3-pole M12 and 4-pole M8 configuration supports compatible devices. Secure locking reduces the possibility of accidental disconnection.
The cable is designed for demanding automation environments. High IP protection supports resistance to moisture and contamination. PUR construction provides mechanical durability. Oil and coolant resistance makes it suitable for machine applications.
0.6 m cable length
M12 3-pole connector
M8 4-pole socket
LED status indication
10–36 V DC LED supply
PUR cable
Halogen-free
Gold-plated contacts
IP67 / IP68 / IP69K
Oil and coolant resistant
Compact installation
Easy visual diagnostics
Industrial sensors
Automation equipment
Machine tools
Status monitoring
Production machinery
Control systems
Factory automation
Sensor diagnostics
| Specification | Details |
|---|---|
| Product Type | Connection Cable with LED |
| Model | VDOAF032MSS00,6H03STGH030MSS |
| Cable Length | 0.6 m |
| Connector A | M12 Plug |
| Connector B | M8 Socket |
| M12 Contacts | 3 |
| M8 Contacts | 4 |
| LED | Yes |
| LED Supply | 10–36 V DC |
| Cable Material | PUR |
| Cable Size | 3 × 0.34 mm² |
| Cable Diameter | Approx. 4.9 mm |
| Cable Colour | Black |
| Cable Type | Halogen-free |
| M12 Voltage | 250 V AC / 300 V DC |
| M8 Voltage | 50 V AC / 60 V DC |
| Current Rating | 3 A |
| Temperature | -25°C to +90°C |
| Protection | IP67 / IP68 / IP69K |
| Housing | TPU |
| Locking | CuZn / nickel-plated |
| Sealing | FKM |
| M8 Torque | 0.3–0.5 Nm |
| M12 Torque | 0.6–1.5 Nm |
| Application | Industrial |
| Pack Quantity | 1 pc |
