EVC225 is a compact 0.3 m M12-to-M8 connection cable with LED indication for industrial automation. It features a 3-pole M12 connector and 4-pole M8 socket with visual status indication. The PUR halogen-free cable provides reliable industrial connectivity. Its compact design is ideal for sensor installations with limited wiring space.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
EVC225 includes LED indication for quick visual monitoring of the connection. The LED configuration helps operators identify operating status directly at the connector. This can simplify machine troubleshooting. It is useful in automation systems requiring fast visual diagnostics.
The 3-pole M12 connector and 4-pole M8 socket provide a compact industrial interface. The connector design supports reliable sensor and actuator connectivity. Secure locking helps maintain the connection. It is suitable for machine-level automation wiring.
The PUR cable provides flexibility and mechanical durability. Its halogen-free construction supports industrial installation requirements. Gold-plated contacts provide reliable electrical transmission. The cable is suitable for continuous automation operation.
The cable is designed for demanding industrial environments. IP protection helps guard against moisture and contaminants. Oil and coolant resistance supports machine-tool applications. Its compact construction works well in restricted installation areas.
0.3 m cable length
M12 3-pole connector
M8 4-pole socket
LED indication
PUR cable
Halogen-free
Gold-plated contacts
10–36 V DC LED supply
IP67 / IP68 / IP69K
Oil and coolant resistant
Compact design
Visual diagnostics
Sensor status monitoring
Factory automation
Machine tools
Industrial sensors
Control systems
Compact machinery
Production equipment
Automation diagnostics
| Specification | Details |
|---|---|
| Product Type | Connection Cable with LED |
| Model | VDOAF032MSS00,3H03STGH030MSS |
| Cable Length | 0.3 m |
| Connector A | M12 Plug |
| Connector B | M8 Socket |
| M12 Contacts | 3 |
| M8 Contacts | 4 |
| LED | Yes |
| LED Supply | 10–36 V DC |
| Cable Material | PUR |
| Cable Construction | 3 × 0.34 mm² |
| Cable Diameter | Approx. 4.9 mm |
| Cable Colour | Black |
| Cable Type | Halogen-free |
| M12 Voltage | 250 V AC / 300 V DC |
| M8 Voltage | 50 V AC / 60 V DC |
| Current Rating | 3 A |
| Temperature | -25°C to +90°C |
| Protection | IP67 / IP68 / IP69K |
| Housing | TPU |
| Locking | CuZn / nickel-plated |
| Sealing | FKM |
| M8 Torque | 0.3–0.5 Nm |
| M12 Torque | 0.6–1.5 Nm |
| Application | Industrial |
| Pack Quantity | 1 pc |
