EVC216 is a 0.6 m M12-to-M8 connection cable designed for compact industrial sensor and automation applications. It features a 3-pole configuration with gold-plated contacts and a PUR halogen-free cable. The cable provides reliable protection in demanding industrial environments. Its compact length supports neat machine-level cable routing.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
EVC216 connects compatible M12 and M8 devices using a 3-pole industrial interface. Gold-plated contacts provide reliable signal transmission. The connectors provide secure mechanical coupling. This makes the cable suitable for industrial sensor systems.
The 0.6 m cable is suitable for short machine connections. Its compact design reduces unnecessary cable loops. PUR construction provides flexibility and durability. It is suitable for space-conscious installations.
The cable is designed for industrial environments involving oils, coolants and moisture. High IP protection supports reliable operation. Sealed connectors help maintain connection integrity. The cable construction supports machine-tool applications.
Drag-chain suitability allows use in moving automation equipment. The cable supports repeated bending. Its flexible construction helps accommodate machine movement. This provides a practical solution for dynamic sensor connections.
0.6 m cable length
M12-to-M8 connection
3-pole design
Gold-plated contacts
PUR cable
Halogen-free
Oil and coolant resistant
High IP protection
Drag-chain suitable
Compact routing
Vibration resistant
Reliable signal connection
Industrial sensors
Factory automation
Machine tools
Actuator systems
Compact machinery
Sensor networks
Control equipment
Dynamic production machinery
| Specification | Details |
|---|---|
| Product Type | Connection Cable |
| Model | VDOGF030MSS00,6H03STGH030MSS |
| Cable Length | 0.6 m |
| Connector A | M12 plug |
| Connector B | M8 socket |
| Design | Straight / Straight |
| Coding | A-coded |
| Contacts | 3 |
| Contact Finish | Gold-plated |
| Cable Material | PUR |
| Cable Size | 3 × 0.34 mm² |
| Cable Diameter | Approx. 4.3 mm |
| Operating Voltage | <50 V AC / <60 V DC |
| Protection Class | III |
| Maximum Current | 3 A |
| Temperature | -25°C to +90°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Housing | TPU |
| Locking | Brass, nickel-plated |
| Sealing | FKM |
| Drag Chain | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Pack Quantity | 1 pc |
