EVC214 is a 5 m M12-to-M8 connection cable intended for industrial automation and sensor applications. The 3-pole configuration provides reliable connectivity between M12 and M8 interfaces. Its PUR halogen-free cable and gold-plated contacts support durable signal transmission. High IP protection makes it suitable for harsh industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The 5 m cable provides extended routing between sensors and automation equipment. Its M12-to-M8 interface supports compact industrial devices. Three gold-plated contacts provide reliable electrical connectivity. The cable is suitable for larger machine layouts.
The PUR cable provides flexibility and mechanical durability. Halogen-free construction supports industrial installation requirements. TPU connector bodies provide protection against mechanical stress. Secure locking components help maintain connection integrity.
The connection is designed for environments exposed to dust, moisture, oils and coolants. High IP protection supports demanding factory conditions. Sealed connectors help maintain reliable performance. This makes EVC214 suitable for machine tools and production equipment.
Drag-chain suitability allows the cable to be installed on moving machinery. More than 5 million bending cycles support long-term operation. The recommended bending radius reduces mechanical stress. This makes it suitable for automated production systems.
5 m cable length
M12-to-M8 connection
3-pole configuration
Gold-plated contacts
PUR cable
Halogen-free
Silicone-free
Oil and coolant resistant
IP65 / IP67 / IP68 / IP69K
Drag-chain suitable
High bending-cycle performance
Industrial-grade construction
Factory automation
Machine tools
Sensor networks
Industrial equipment
Actuator systems
Production lines
Conveyor machinery
Dynamic automation
| Specification | Details |
|---|---|
| Product Type | Connection Cable |
| Model | VDOAF040MSS0005H03STGH030MSS |
| Cable Length | 5 m |
| Connector A | M12 plug |
| Connector B | M8 socket |
| M12 Design | Straight |
| M8 Design | Angled |
| Coding | A-coded |
| Contacts | 3 |
| Contact Finish | Gold-plated |
| Cable Material | PUR |
| Cable Size | 3 × 0.34 mm² |
| Cable Diameter | Ø 4.3 mm |
| Operating Voltage | <50 V AC / <60 V DC |
| Protection Class | III |
| Maximum Current | 3 A |
| Temperature | -25°C to +90°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Housing | TPU |
| Locking | Brass, nickel-plated |
| Sealing | FKM |
| Drag Chain | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Pack Quantity | 1 pc |
