EVC212 is a 1 m M12-to-M8 connection cable designed for compact industrial automation and sensor applications. It features a 3-pole M12 plug and M8 socket configuration with gold-plated contacts. The PUR cable is halogen-free and resistant to oils and coolants. High IP protection and drag-chain suitability provide reliable performance in demanding environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
EVC212 connects compatible M12 and M8 industrial interfaces in automation systems. The 3-pole configuration is suitable for compact sensor and actuator connections. Gold-plated contacts support reliable electrical transmission. The standardized connectors simplify machine-level installation.
The 1 m cable length is suitable for short-distance equipment connections. It helps minimize excess wiring around sensors and machinery. PUR construction provides flexibility and durability. The compact length is useful for organized machine wiring.
The cable is designed for demanding industrial environments. IP65, IP67, IP68 and IP69K protection helps protect the connection from dust and moisture. Oil and coolant resistance supports machine-tool applications. The sealed construction provides dependable connection integrity.
EVC212 is suitable for applications involving repeated cable movement. Drag-chain suitability supports automated machinery. The cable supports more than 5 million bending cycles. A minimum bending radius of 10 times the cable diameter helps reduce mechanical stress.
1 m cable length
M12-to-M8 connection
3-pole configuration
Straight M12 plug
Angled M8 socket
Gold-plated contacts
PUR cable
Halogen-free construction
Oil and coolant resistant
IP65 / IP67 / IP68 / IP69K
Drag-chain suitable
More than 5 million bending cycles
Industrial sensors
Factory automation
Machine tools
Compact machinery
Sensor connections
Actuator systems
Control equipment
Dynamic automation
| Specification | Details |
|---|---|
| Product Type | Connection Cable |
| Model | VDOAF040MSS0001H03STGH030MSS |
| Cable Length | 1 m |
| Connector A | M12 plug |
| Connector B | M8 socket |
| M12 Design | Straight |
| M8 Design | Angled |
| Coding | A-coded |
| Contacts | 3 |
| Contact Finish | Gold-plated |
| Cable Material | PUR |
| Cable Construction | 3 × 0.34 mm² |
| Cable Diameter | Ø 4.3 mm |
| Cable Colour | Black |
| Operating Voltage | <50 V AC / <60 V DC |
| Protection Class | III |
| Maximum Current | 3 A |
| Temperature | -25°C to +90°C |
| cULus Temperature | Up to 75°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Housing | TPU, orange |
| Locking | Brass, nickel-plated |
| Sealing | FKM |
| M12 Tightening Torque | 0.6–1.5 Nm |
| M8 Tightening Torque | 0.3–0.5 Nm |
| Drag Chain | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Pack Quantity | 1 pc |
