EVC210 is a compact 0.3 m M12-to-M8 connection cable designed for sensor and actuator connectivity. It combines a straight M12 plug with an angled M8 socket in a 3-pole configuration. The PUR cable is halogen-free and suitable for industrial applications. High IP protection provides reliable operation in demanding environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
EVC210 connects an M12 industrial interface to an M8 interface. The 3-pole configuration is suitable for compact sensor and actuator connections. The straight M12 plug and angled M8 socket provide flexible installation. Gold-plated contacts support reliable electrical performance.
The 0.3 m cable length is suitable for short-distance connections. Its compact design helps reduce cable clutter around machines. The angled M8 connector can simplify routing in restricted spaces. It is particularly useful for compact sensor installations.
The cable uses black PUR material with a 3 × 0.34 mm² construction. It is halogen-free and designed for industrial use. The connector housings provide mechanical protection. Brass, nickel-plated locking components provide secure connections.
EVC210 supports IP65, IP67, IP68 and IP69K protection. The cable is resistant to oils and coolants. The sealed construction supports reliable operation in machine environments. Its mechanical design supports vibration and shock resistance.
0.3 m cable length
M12 plug to M8 socket
3-pole configuration
Straight M12 plug
Angled M8 socket
Gold-plated contacts
PUR cable
Halogen-free
60 V operating class
IP65 / IP67 / IP68 / IP69K
Oil and coolant resistant
Compact installation
Industrial sensors
Compact automation equipment
M8 sensor connections
M12-to-M8 adaptation
Factory automation
Machine tools
Control equipment
Sensor networks
| Specification | Details |
|---|---|
| Product Type | Connection Cable |
| Model | VDOAF040MSS00,3H03STGH030MSS |
| Cable Length | 0.3 m |
| Connector A | M12 plug |
| Connector B | M8 socket |
| Plug Design | Straight |
| Socket Design | Angled |
| Coding | A-coded |
| Contacts | 3 |
| Contact Finish | Gold-plated |
| Cable Material | PUR |
| Cable Size | 3 × 0.34 mm² |
| Cable Diameter | Ø 4.3 mm |
| Cable Colour | Black |
| Electrical Design | AC/DC |
| Operating Voltage | <50 V AC / <60 V DC |
| Protection Class | III |
| Temperature | -25°C to +90°C |
| cULus Temperature | Max. 75°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Housing | TPU |
| Locking | Brass, nickel-plated |
| Sealing | FKM |
| M8 Tightening Torque | 0.3–0.5 Nm |
| M12 Tightening Torque | 0.6–1.5 Nm |
| Drag Chain | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Pack Quantity | 1 pc |
