EVC206 is a 3 m M12 connection cable designed for industrial sensor and automation applications. It provides a 5-pole M12 plug-to-socket connection with angled and straight connector configuration. Gold-plated contacts and PUR cable construction support reliable signal transmission. High IP protection and drag-chain suitability make it suitable for demanding machine environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
EVC206 provides a 3 m connection between compatible industrial devices. Its 5-pole M12 design supports multiple signal connections. The angled and straight connector combination simplifies cable routing. Gold-plated contacts support stable electrical performance.
The cable is manufactured with PUR material and a black outer sheath. The cable is free from halogens and silicone. TPU connector housing provides mechanical protection. Nickel-plated brass locking components provide secure connection.
EVC206 supports IP65, IP67, IP68 and IP69K protection. It is suitable for industrial environments involving oils and coolants. FKM/Viton sealing supports reliable protection. The construction is designed for vibration and shock resistance.
The cable is suitable for drag-chain applications. It supports more than 5 million bending cycles. The minimum bending radius is 10 times the cable diameter. Travel speed can reach up to 3.3 m/s under specified conditions.
3 m cable length
5-pole M12 plug-to-socket
Angled / straight configuration
Gold-plated contacts
PUR cable
Halogen-free
Silicone-free
60 V AC/DC
4 A current rating
IP65 / IP67 / IP68 / IP69K
Drag-chain suitable
More than 5 million bending cycles
Factory automation
Machine tools
Industrial sensors
Actuator systems
Production machinery
Conveyor systems
Control equipment
Dynamic machinery
| Specification | Details |
|---|---|
| Product Type | Connection / Jumper Cable |
| Model | VDOGH050MSS0003H05STAH050MSS |
| Cable Length | 3 m |
| Connector | M12 plug / M12 socket |
| Configuration | Angled / Straight |
| Coding | A-coded |
| Contacts | 5 |
| Contact Finish | Gold-plated |
| Cable Material | PUR |
| Cable Size | 5 × 0.34 mm² |
| Cable Diameter | Ø 4.9 mm |
| Cable Colour | Black |
| Operating Voltage | 60 V AC/DC |
| Current Rating | 4 A |
| cULus Current | 3 A |
| Protection Class | II |
| Temperature | -25°C to +90°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Housing | TPU orange |
| Locking | Brass, nickel-plated |
| Sealing | FKM |
| Drag Chain | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Weight | Approx. 131 g |
| Pack Quantity | 1 pc |
