EVC196 is a 1 m M12 connecting cable with a straight 5-pole socket designed for industrial sensor connectivity. It features gold-plated contacts, PUR halogen-free cable and robust environmental protection. The cable is resistant to oils and coolants commonly found in machine applications. Drag-chain suitability supports reliable use in dynamic machinery.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
EVC196 provides a straight M12 socket for direct connection to compatible sensors and devices. The 5-pole configuration supports multiple electrical signals. Gold-plated contacts provide reliable connectivity. The connector is designed for secure industrial installation.
The 1 m PUR cable provides convenient short-distance routing. The cable is halogen-free and silicone-free. Its compact length helps reduce excess cable around machinery. TPU housing provides mechanical protection.
EVC196 provides IP65, IP67, IP68 and IP69K protection. It is resistant to oils and coolants. FKM sealing helps maintain reliable sealing during operation. The coupling ring and mechanical end stop help protect the sealing system.
The cable is suitable for drag-chain applications. It supports more than 5 million bending cycles. The minimum bending radius is 10 times the cable diameter. This provides dependable performance in moving machinery.
1 m cable length
M12 straight socket
5-pole A-coded connection
Gold-plated contacts
PUR halogen-free cable
Silicone-free
IP65 / IP67 / IP68 / IP69K
Oil and coolant resistant
FKM sealing
Drag-chain suitable
More than 5 million bending cycles
Industrial sensors
Factory automation
Machine tools
Sensor connections
Control equipment
Production machinery
Conveyor systems
Dynamic automation
| Specification | Details |
|---|---|
| Product Type | Connecting Cable with Socket |
| Model | ADOGH050MSS0001H05 |
| Cable Length | 1 m |
| Connector | M12 socket |
| Design | Straight |
| Coding | A-coded |
| Contacts | 5, gold-plated |
| Cable Material | PUR |
| Cable Size | 5 × 0.34 mm² |
| Cable Diameter | Ø 4.6 mm |
| Operating Voltage | <60 V AC/DC |
| Current Rating | 4 A |
| UL Current Rating | 3 A |
| Protection Class | II |
| Temperature | -25°C to +90°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Housing | TPU orange |
| Locking | Brass, nickel-plated |
| Sealing | FKM |
| Tightening Torque | 0.6–1.5 Nm |
| Drag Chain | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Weight | Approx. 54.2 g |
| Pack Quantity | 1 pc |
