EVC174 is a 1.8 m M12 connection cable designed for industrial sensor and automation applications. It features a 3-pole connection, gold-plated contacts and a halogen-free PUR cable. Its IP65, IP67, IP68 and IP69K protection supports demanding industrial environments. The cable is also suitable for drag-chain and dynamic machine applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
EVC174 provides standardized M12 connectivity for industrial sensors and automation equipment. The 1.8 m cable length is suitable for compact and medium-sized machine installations. Gold-plated contacts help maintain stable electrical connections. The 3-pole configuration supports common sensor applications.
The cable uses PUR construction designed for industrial use. Its halogen-free and silicone-free properties support demanding installations. TPU housing and FKM sealing provide mechanical and environmental protection. Nickel-plated brass locking components provide secure connection.
EVC174 provides IP65, IP67, IP68 and IP69K protection. It is suitable for environments exposed to moisture, dust, oils and coolants. The sealed connection supports reliable operation during industrial cleaning. This makes it suitable for machine tools and factory automation.
The cable is suitable for drag-chain applications and repeated movement. It supports high bending-cycle performance. The minimum bending radius is 10 times the cable diameter. This makes it suitable for moving machinery and automated production systems.
1.8 m cable length
M12 3-pole connection
Gold-plated contacts
PUR halogen-free cable
Silicone-free construction
IP65 / IP67 / IP68 / IP69K
Oil and coolant resistant
FKM sealing
Drag-chain suitable
High bending-cycle performance
Industrial sensors
Factory automation
Machine tools
Conveyor equipment
Production machinery
Sensor connections
Automation systems
Dynamic equipment
| Specification | Details |
|---|---|
| Product Type | Connection / Jumper Cable |
| Model | VDOGH030MSS01,8H03STGH030MSS |
| Cable Length | 1.8 m |
| Connector | M12 |
| Contacts | 3, gold-plated |
| Coding | A-coded |
| Cable Material | PUR |
| Cable Size | 3 × 0.34 mm² |
| Cable Diameter | Ø 4.3 mm |
| Operating Voltage | <250 V AC / <300 V DC |
| Current Rating | 4 A |
| Protection Class | II |
| Temperature | -25°C to +90°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Housing | TPU, orange |
| Sealing | FKM |
| Nut | Brass, nickel-plated |
| Drag Chain | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Weight | Approx. 80 g |
| Pack Quantity | 1 pc |
