EVC164 is a 2 m M12 connecting cable with an angled 2-pole socket designed for industrial sensor applications. The angled connector provides flexible routing where installation space is limited. Gold-plated contacts, PUR halogen-free cable and FKM sealing support reliable operation. IP65, IP67, IP68 and IP69K protection makes it suitable for demanding environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Angled M12 Connectivity
The angled socket allows convenient cable routing around sensors and machine structures. The 2 m cable provides practical connection distance. Gold-plated contacts support stable electrical connectivity. The 2-pole design is suitable for compact sensor applications.
Compact Installation
The angled connector is particularly useful in installations where straight cable routing is restricted. TPU housing provides mechanical protection. The locking nut ensures a secure connection. The compact design helps simplify sensor installation.
Harsh Environment Resistance
EVC164 provides IP65, IP67, IP68 and IP69K protection. The cable is suitable for oils, coolants and demanding machine environments. FKM sealing provides reliable environmental protection. The PUR cable is halogen-free and silicone-free.
Dynamic Machine Performance
The cable is suitable for drag-chain applications. More than 5 million bending cycles are supported. A minimum bending radius of 10 times the cable diameter is specified. This supports reliable operation in moving machinery.
2 m cable length
Angled M12 socket
2-pole connection
Gold-plated contacts
PUR halogen-free cable
Silicone-free
IP65 / IP67 / IP68 / IP69K
Oil and coolant resistant
FKM sealing
Drag-chain suitable
High bending-cycle capability
Industrial sensors
Machine tools
Factory automation
Conveyor equipment
Automation systems
Sensor connections
Dynamic machinery
| Specification | Details |
|---|---|
| Product Type | Connecting Cable with Socket |
| Model | ADOAH020MSS0002H02 |
| Cable Length | 2 m |
| Connector | M12 socket |
| Design | Angled |
| Coding | A-coded |
| Contacts | 2, gold-plated |
| Cable Material | PUR |
| Cable Size | 2 × 0.34 mm² |
| Cable Diameter | Ø 4.9 mm |
| Operating Voltage | 250 V AC / 300 V DC |
| Current Rating | 4 A |
| Protection Class | II |
| Temperature | -25°C to +90°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Housing | TPU orange |
| Nut | Brass, nickel-plated |
| Sealing | FKM |
| Tightening Torque | 0.6–1.5 Nm |
| Drag Chain | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Weight | Approx. 73–80 g |
| Pack Quantity | 1 pc |
