EVC161 is a 2 m M12 connecting cable with a straight 2-pole socket designed for industrial sensor connectivity. It features gold-plated contacts, a halogen-free PUR cable and durable FKM sealing. The cable provides IP65, IP67, IP68 and IP69K protection for demanding industrial environments. Its drag-chain suitability makes it suitable for applications involving repeated cable movement.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Reliable M12 Connectivity
EVC161 provides a dependable 2-pole M12 connection for industrial sensors and automation equipment. The straight socket design enables simple and direct installation. Gold-plated contacts support stable electrical connectivity. It is suitable for general industrial and factory automation applications.
Durable PUR Cable Construction
The cable uses a black, halogen-free PUR jacket with 2 × 0.34 mm² conductors. PUR construction provides flexibility and resistance for industrial environments. The cable is also silicone-free. FKM sealing provides reliable connector protection.
High Environmental Protection
EVC161 provides IP65, IP67, IP68 and IP69K protection. It is designed for applications involving oils and coolants. The sealed connector construction helps protect against dust and moisture. This makes it suitable for machine tools and demanding factory environments.
Dynamic Machine Applications
The cable is suitable for drag-chain applications and repeated movement. It supports more than 5 million bending cycles. A minimum bending radius of 10 times the cable diameter helps protect the cable during movement. The design supports reliable long-term machine operation.
2 m cable length
M12 straight socket
2-pole connection
Gold-plated contacts
PUR halogen-free cable
Silicone-free construction
IP65 / IP67 / IP68 / IP69K
FKM sealing
Oil and coolant resistant
Drag-chain suitable
More than 5 million bending cycles
Industrial sensors
Factory automation
Machine tools
Sensor connections
Automation equipment
Conveyor systems
Dynamic machinery
| Specification | Details |
|---|---|
| Product Type | Connecting Cable with Socket |
| Model | ADOGH020MSS0002H02 |
| Cable Length | 2 m |
| Connector | M12 socket |
| Connector Design | Straight |
| Coding | A-coded |
| Contacts | 2, gold-plated |
| Cable Material | PUR |
| Cable Size | 2 × 0.34 mm² |
| Cable Diameter | Ø 4.9 mm |
| Operating Voltage | <250 V AC / <300 V DC |
| Current Rating | 4 A |
| Protection Class | II |
| Operating Temperature | -25°C to +90°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Housing | TPU, orange |
| Nut | Brass, nickel-plated |
| Sealing | FKM |
| Tightening Torque | 0.6–1.5 Nm |
| Drag Chain | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Weight | 75.4 g |
| Pack Quantity | 1 pc |
