EVC152 is a 10 m M8 connecting cable designed for extended industrial sensor and automation connectivity. It uses a straight 4-pole M8 socket, gold-plated contacts and a halogen-free PUR cable. The cable offers high IP protection and resistance to oils and coolants. It is suitable for long-distance routing and dynamic machine applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Long-Distance Sensor Connectivity
The 10 m cable provides extended reach between field sensors and automation equipment. Its M8 A-coded socket supports standardized industrial connectivity. Gold-plated contacts help maintain reliable signal transmission. The straight configuration makes installation straightforward.
Industrial Durability
The PUR cable provides flexibility and resistance to demanding industrial conditions. The TPU connector body and FKM seal support long-term durability. Nickel-plated brass provides secure mechanical locking. The construction is suitable for factory automation.
Environmental Protection
IP65, IP67, IP68 and IP69K ratings protect the connection against dust, moisture and industrial cleaning conditions. The cable is designed for use around oils and coolants. This makes it suitable for machine tools and production equipment.
Dynamic Cable Routing
EVC152 supports drag-chain applications where repeated movement occurs. It is designed for more than 5 million bending cycles. The minimum bending radius is 10 times the cable diameter. This provides reliable operation in moving machinery.
10 m cable length
M8 straight socket
4 gold-plated contacts
A-coded connection
PUR halogen-free cable
Oil and coolant resistant
IP65 / IP67 / IP68 / IP69K
FKM sealing
Drag-chain compatible
High mechanical durability
Industrial automation
Machine tools
Sensor networks
Conveyor systems
Production lines
Actuator connections
Dynamic machinery
| Specification | Details |
|---|---|
| Product Type | Connecting Cable with Socket |
| Model | ADOGF040MSS0010H04 |
| Cable Length | 10 m |
| Connector | M8 socket |
| Design | Straight |
| Coding | A-coded |
| Contacts | 4, gold-plated |
| Cable Material | PUR |
| Cable Size | 4 × 0.25 mm² |
| Cable Diameter | Ø 3.7 mm |
| Operating Voltage | <50 V AC / <60 V DC |
| Current Rating | 3 A |
| Protection Class | III |
| Temperature | -25°C to +90°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Housing | TPU orange |
| Nut | Nickel-plated brass |
| Sealing | FKM |
| Drag Chain | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Weight | Approx. 222.5 g |
| Pack Quantity | 1 pc |
