EVC148 is a 5 m angled M8 connecting cable designed for PNP sensor and automation applications. Integrated green and yellow LEDs provide quick visual confirmation of operation and switching status. The cable features gold-plated contacts, PUR halogen-free construction and high IP protection. Its drag-chain suitability supports dynamic machine applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PNP Automation Connectivity
EVC148 operates with 10–36 V DC and uses a PNP electrical design. The 5 m cable provides extended connection distance for industrial equipment. Its angled M8 socket simplifies routing around machinery. Gold-plated contacts provide dependable electrical connection.
Visual Status Monitoring
The integrated green operation LED and yellow switching-status LED allow quick visual inspection. This makes commissioning and troubleshooting easier. The indicators remain useful in industrial environments. Operators can identify device status without additional diagnostic equipment.
Harsh Environment Protection
The cable is protected against demanding industrial conditions with IP65, IP67, IP68 and IP69K ratings. PUR construction and FKM sealing improve durability. It is resistant to oils and coolants. The cable is also halogen-free and silicone-free.
Dynamic Machine Operation
EVC148 supports drag-chain installations and repeated cable movement. It supports more than 5 million bending cycles. The minimum bending radius is 10 times the cable diameter. This makes it suitable for automated machinery.
5 m cable length
Angled M8 socket
3 gold-plated contacts
10–36 V DC
PNP electrical design
Green operation LED
Yellow switching LED
PUR halogen-free cable
IP65 / IP67 / IP68 / IP69K
Drag-chain suitable
PNP sensors
Factory automation
Machine tools
Conveyor systems
Industrial monitoring
Production machinery
Dynamic automation systems
| Specification | Details |
|---|---|
| Product Type | Connecting Cable with Socket |
| Model | ADOAF032MSS0005H03 |
| Cable Length | 5 m |
| Connector | M8 socket |
| Design | Angled |
| Coding | A-coded |
| Contacts | 3, gold-plated |
| Cable Material | PUR |
| Cable Size | 3 × 0.25 mm² |
| Cable Diameter | Ø 3.7 mm |
| Operating Voltage | 10–36 V DC |
| Current Rating | 3 A |
| Electrical Design | PNP |
| Protection Class | III |
| Temperature | -25°C to +90°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Housing | TPU black transparent |
| Nut | Nickel-plated brass |
| Sealing | FKM |
| LEDs | 1 green + 1 yellow |
| Drag Chain | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Bending Cycles | >5 million |
| Travel Speed | Max. 3.3 m/s |
| MTTF | 31,710 years |
| Weight | 110.8 g |
| Pack Quantity | 1 pc |
