EVC147 is a 2 m M8 connecting cable with an angled socket and integrated LED status indication. It is designed for PNP industrial sensor applications requiring clear operating and switching-status feedback. The cable features gold-plated contacts, halogen-free PUR construction and high IP protection. Drag-chain suitability makes it suitable for dynamic factory automation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
PNP Sensor Connectivity
EVC147 is designed for 10–36 V DC PNP applications. Its angled M8 socket provides convenient sensor connection in restricted spaces. Gold-plated contacts support reliable electrical performance. The 2 m cable provides practical machine-level connectivity.
LED Status Indication
Integrated green and yellow LEDs provide clear operating and switching-status indication. The LEDs remain visible even under bright industrial lighting. This helps technicians identify sensor status quickly. It can simplify commissioning and troubleshooting.
Industrial Protection
The cable is halogen-free and silicone-free. IP65, IP67, IP68 and IP69K protection supports demanding industrial environments. FKM sealing and TPU housing improve durability. The cable is resistant to oils and coolants.
Dynamic Applications
EVC147 is suitable for drag-chain applications. It supports more than 5 million bending cycles and a minimum bending radius of 10 times the cable diameter. This makes it suitable for automated machinery.
2 m cable length
Angled M8 socket
3 gold-plated contacts
10–36 V DC operation
PNP electrical design
Green operation LED
Yellow switching-status LED
PUR halogen-free cable
IP65 / IP67 / IP68 / IP69K
Drag-chain suitable
PNP sensors
Factory automation
Machine tools
Sensor monitoring
Conveyor systems
Production machinery
Automation control systems
| Specification | Details |
|---|---|
| Product Type | Connecting Cable with Socket |
| Model | ADOAF032MSS0002H03 |
| Cable Length | 2 m |
| Connector | M8 socket |
| Design | Angled |
| Coding | A-coded |
| Contacts | 3, gold-plated |
| Cable Material | PUR |
| Cable Size | 3 × 0.25 mm² |
| Cable Diameter | Ø 3.7 mm |
| Operating Voltage | 10–36 V DC |
| Current Rating | 3 A |
| Electrical Design | PNP |
| Protection Class | III |
| Temperature | -25°C to +90°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Housing | TPU black transparent |
| Nut | Nickel-plated brass |
| Sealing | FKM |
| LEDs | 1 green + 1 yellow |
| Drag Chain | Yes |
| Bending Radius | Min. 10 × cable diameter |
| Bending Cycles | >5 million |
| Travel Speed | Max. 3.3 m/s |
| MTTF | 31,710 years |
| Weight | 52.9 g |
| Pack Quantity | 1 pc |
