EVC081 is a 10 m industrial connecting cable with a straight 4-pole M12 plug. It provides extended connectivity for sensors and automation equipment installed across larger machines. The PUR cable offers flexibility and industrial durability. Gold-plated contacts and high environmental protection support reliable operation.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The straight M12 plug provides dependable connectivity for compatible automation equipment. Four gold-plated contacts support stable signal transmission. The locking system provides secure mechanical coupling. It is suitable for standard industrial connection applications.
The 10 m length is useful for larger machinery and distributed sensor layouts. It allows longer distances between connected devices. Flexible PUR construction simplifies routing. It can reduce the requirement for intermediate extensions.
The cable is designed for demanding industrial environments. PUR construction provides flexibility and mechanical strength. Halogen-free and silicone-free construction supports industrial requirements. Vibration and shock resistance improve durability.
The cable is suitable for environments exposed to oils, coolants and lubricants. High IP protection helps protect the connection. Reliable sealing supports long-term operation.
10 m cable length
Straight M12 plug
4-pole connection
PUR construction
Halogen-free
Silicone-free
Gold-plated contacts
Oil resistant
Coolant resistant
Vibration resistant
Shock resistant
Drag-chain suitable
High IP protection
Large machinery
Factory automation
Machine tools
Industrial sensors
Production lines
Conveyor systems
Control equipment
Automation panels
| Specification | Details |
|---|---|
| Product Type | Connecting Cable with Plug |
| Model | ASTAH040MSS0010H04 |
| Cable Length | 10 m |
| Connector | M12 Plug |
| Design | Straight |
| Contacts | 4 |
| Coding | A |
| Cable Material | PUR |
| Cable Size | 4 × 0.34 mm² |
| Contact Finish | Gold-plated |
| Housing | TPU |
| Locking | Brass, nickel-plated |
| Sealing | FKM |
| Operating Voltage | <250 V AC / <300 V DC |
| Current Rating | 4 A |
| Temperature | -25°C to +90°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Drag Chain | Yes |
| Pack Quantity | 1 pc |
