EVC080 is a 5 m industrial connecting cable with a straight 4-pole M12 plug. It provides reliable connectivity for sensors and automation equipment. The PUR cable combines flexibility with resistance to oils, coolants and mechanical stress. It is suitable for factory automation and machine-tool applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The straight M12 plug provides secure connection to compatible industrial devices. Four contacts support common automation signals. Gold-plated contacts help ensure dependable transmission. The locking system maintains connection stability.
The 5 m cable offers extended routing capability for machine installations. It can connect equipment positioned at moderate distances. Flexible PUR construction supports easy cable routing. It reduces dependence on extension cables.
The cable is manufactured for demanding industrial environments. PUR construction provides mechanical durability. The cable is halogen-free and silicone-free. Vibration and shock resistance support reliable operation.
EVC080 is suitable for industrial automation and machine-tool applications. It can be used in environments exposed to coolants and lubricants. High protection helps protect against moisture and contaminants.
5 m cable length
Straight M12 plug
4-pole connection
PUR cable
Halogen-free
Silicone-free
Gold-plated contacts
Oil resistant
Coolant resistant
Shock resistant
Vibration resistant
Drag-chain suitable
High IP protection
Machine tools
Factory automation
Industrial sensors
Production machinery
Conveyors
Actuator systems
Control equipment
Automation systems
| Specification | Details |
|---|---|
| Product Type | Connecting Cable with Plug |
| Model | ASTAH040MSS0005H04 |
| Cable Length | 5 m |
| Connector | M12 Plug |
| Design | Straight |
| Contacts | 4 |
| Coding | A |
| Cable Material | PUR |
| Cable Size | 4 × 0.34 mm² |
| Contact Finish | Gold-plated |
| Housing | TPU |
| Locking | Brass, nickel-plated |
| Sealing | FKM |
| Operating Voltage | <250 V AC / <300 V DC |
| Current Rating | 4 A |
| Temperature | -25°C to +90°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Drag Chain | Yes |
| Pack Quantity | 1 pc |
