EVC053 is a 2 m DC PNP M12 connection cable designed for dependable sensor and actuator connectivity. It combines a straight plug with an angled socket for flexible industrial routing. The cable uses a black PUR jacket with gold-plated contacts. Integrated LEDs provide convenient power and switching-status indication.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
EVC053 supports 10–36 V DC operation with a 4 A current rating. It is designed for factory automation and machine-tool applications. The angled socket helps simplify cable routing around equipment. High IP protection and durable materials support reliable operation in harsh industrial conditions.
The cable uses a straight M12 plug and angled M12 socket with A coding. Three gold-plated contacts provide stable electrical connectivity. TPU housings with nickel-plated brass locking components provide secure coupling. Yellow and green LEDs provide quick visual feedback for switching and power status.
EVC053 uses a 2 m black PUR cable with three 0.34 mm² conductors and approximately 4.9 mm diameter. The cable is halogen-free and silicone-free. Drag-chain suitability supports repeated machine movement. More than five million bending cycles are supported under specified conditions.
The cable operates from 10–36 V DC and supports up to 4 A. It operates from -25 to +90 °C, with cULus operation up to 75 °C. IP65/IP67/IP68/IP69K protection provides resistance to harsh environmental conditions. Oil, coolant, vibration and shock resistance support machine automation applications.
2 m cable length
DC PNP design
10–36 V DC
4 A current rating
Straight M12 plug
Angled M12 socket
3 gold-plated contacts
Yellow switching LED
Green power LED
PUR jacket
Halogen-free
Silicone-free
IP69K protection
Industrial automation
PNP sensor connections
Machine tools
Actuator wiring
Factory equipment
Sensor diagnostics
Moving machinery
Control systems
| Specification | Details |
|---|---|
| Product Type | Connection Cable |
| Order Number | EVC053 |
| Model | VDOAH032MSS0002H03STGH030MSS |
| Cable Length | 2 m |
| Electrical Design | DC PNP |
| Operating Voltage | 10–36 V DC |
| Current Rating | 4 A |
| Plug | M12, straight |
| Socket | M12, angled |
| Coding | A |
| Contacts | 3, gold-plated |
| Cable Material | PUR |
| Conductors | 3 × 0.34 mm² |
| Cable Diameter | Approx. 4.9 mm |
| Housing | TPU |
| Locking Nut | Brass, nickel-plated |
| Sealing | FKM/Viton |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Ambient Temperature | -25...90 °C |
| Status LED | Yellow |
| Power LED | Green |
| Bending Cycles | >5 million |
| Drag Chain | Yes |
