EVC045 is a compact 0.3 m M12 connection cable designed for reliable industrial automation connections. It combines a straight M12 plug with an angled M12 socket for flexible machine-level routing. The cable uses halogen-free PUR insulation and gold-plated contacts. Its rugged construction supports operation in harsh industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
EVC045 is designed for short-distance AC/DC connections between compatible sensors, actuators and automation equipment. It supports less than 250 V AC or 300 V DC with a maximum current rating of 4 A. The mixed straight-and-angled connector design helps simplify routing in restricted spaces. High IP protection supports machine-tool and factory automation applications.
The cable uses a straight M12 plug and angled M12 socket, both with A coding. Three gold-plated contacts provide stable electrical transmission. TPU connector bodies and nickel-plated brass locking components provide secure mechanical coupling. FKM/Viton sealing provides reliable protection against moisture and contaminants.
EVC045 uses a 0.3 m black PUR cable with three 0.34 mm² conductors. The cable is halogen-free and silicone-free. Its flexible design supports drag-chain applications and repeated movement. More than five million bending cycles are supported under specified conditions.
EVC045 supports <250 V AC / <300 V DC and up to 4 A current. It operates from -25 to +90 °C and provides IP65/IP67/IP68/IP69K protection. The cable is resistant to oils and coolants used in industrial machinery. Its coupling system provides resistance against vibration and shock.
0.3 m compact cable
Straight M12 plug
Angled M12 socket
A-coded interface
Three gold-plated contacts
PUR cable
Halogen-free
Silicone-free
IP69K protection
Drag-chain suitable
Oil resistant
Coolant resistant
Vibration resistant
Compact automation systems
Machine tools
Sensor connections
Actuator connections
Factory automation
Industrial machinery
Control equipment
Moving applications
| Specification | Details |
|---|---|
| Product Type | Connection Cable |
| Order Number | EVC045 |
| Model | VDOAH030MSS00,3H03STGH030MSS |
| Cable Length | 0.3 m |
| Electrical Design | AC/DC |
| Operating Voltage | <250 V AC / <300 V DC |
| Current Rating | 4 A |
| Protection Class | II |
| Plug | M12, straight |
| Socket | M12, angled |
| Coding | A |
| Contacts | 3, gold-plated |
| Cable Material | PUR |
| Conductors | 3 × 0.34 mm² |
| Cable Diameter | Approx. 4.9 mm |
| Cable Colour | Black |
| Housing | TPU |
| Locking Nut | Brass, nickel-plated |
| Sealing | FKM/Viton |
| Protection | IP65/IP67/IP68/IP69K |
| Ambient Temperature | -25...90 °C |
| Bending Radius | Min. 10 × cable diameter |
| Bending Cycles | >5 million |
| Travel Speed | Max. 3.3 m/s |
| Torsional Strain | ±180°/m |
