The ECN07A is a compact IFM connecting cable with socket for industrial sensor and automation applications. It features a 2 m PUR cable and a 5-pin M12 straight connector. Its halogen-free cable, gold-plated contacts and robust sealing provide dependable signal and power connections in demanding environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Introduction
ECN07A provides a ready-to-install connection between compatible sensors and control equipment. The pre-configured M12 connector helps reduce installation effort and provides consistent electrical connectivity.
Connection Design
The cable features a straight M12 A-coded connector with 5 gold-plated contacts. The connector construction is designed for secure and reliable industrial connections.
Cable Construction
The 2 m cable uses PUR insulation and a halogen-free construction. The flexible cable design supports practical routing in automation equipment and machinery.
Industrial & Hazardous Area Performance
The connector provides high protection against environmental influences and is suitable for hazardous-area applications when used according to its approved conditions. The design also provides resistance to vibration and shock.
KEY FEATURES
2 m cable length
Straight M12 connector
A-coded connector
5 gold-plated contacts
PUR cable
Halogen-free construction
TPU connector body
Nickel-plated brass locking nut
FKM sealing
Reliable vibration-resistant connection
High environmental protection
ATEX/IECEx suitable design
APPLICATIONS
Industrial sensors
Automation control systems
Machine wiring
Process instrumentation
Hazardous-area installations
Industrial control panels
| Specification | Details |
|---|---|
| Product Code | ECN07A |
| Model | ADOGH050MSN0002H05/1G/1D |
| Product Type | Connecting cable with socket |
| Cable Length | 2 m |
| Connector | M12 straight |
| Coding | A-coded |
| Contacts | 5, gold-plated |
| Cable Material | PUR |
| Cable Construction | Halogen-free |
| Connector Body | TPU |
| Locking Nut | Brass, nickel-plated |
| Sealing | FKM |
| Operating Voltage | < 30 V DC |
| Protection | IP67 |
| Application | Hazardous-area and industrial applications |
