EC2016 is an IFM R360 load-dump module designed to protect electronic equipment from voltage spikes in 24 V generator-battery systems. It provides external overvoltage protection for electronics used in mobile machinery. The module supports 24 V DC operation with peak current capability up to 75 A. Its robust design is suitable for demanding vehicle and industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
Product Overview
EC2016 provides external protection for electronic components connected to 24 V battery-generator supply systems. It is designed specifically for applications where electrical voltage transients can occur.
Overvoltage Protection
The module protects connected electronics against damaging voltage spikes and supports a peak current of up to 75 A with a peak voltage up to 50 V.
Industrial Performance
EC2016 is designed for demanding operating environments, with an ambient temperature range from -40 °C to +85 °C. Its compact 69 × 96 × 33 mm housing supports practical machine installation.
Application Performance
The module is suitable for 24 V mobile machinery, vehicle electronics, industrial control equipment and battery-powered automation systems.
Key Features
ifm R360 load-dump module
24 V DC operating voltage
External overvoltage protection
Peak current up to 75 A
Peak voltage up to 50 V
ISO 7637-2 pulse 5A EMC testing
-40 °C to +85 °C ambient temperature
Four 6.3 mm flat-pin connections
Compact construction
Designed for mobile machine electronics
Applications
24 V mobile machinery
Vehicle electrical systems
Industrial automation equipment
Mobile machine controllers
Generator-battery supply systems
Electronic equipment protection
Vehicle control systems
Industrial electrical installations
| Specification | Details |
|---|---|
| Product Code | EC2016 |
| Product Type | Load-dump module |
| Series | R360 |
| Designation | R360/LOAD-DUMP-MODULE/24VDC |
| Operating Voltage | 24 V DC |
| Peak Current | ≤ 75 A |
| Peak Voltage | ≤ 50 V |
| Ambient Temperature | -40 °C to +85 °C |
| EMC | ISO 7637-2 pulse 5A |
| Dimensions | 69 × 96 × 33 mm |
| Weight | Approx. 202 g |
| Connector | 4 × flat-pin connector, 6.3 mm |
| Pack Quantity | 1 piece |
| Manufacturer | IFM |
