EBT009 is a 5-pole M12 Y-splitter with one M12 plug and two M12 sockets. It is designed for applications requiring multiple inputs and outputs where installation space is restricted. Gold-plated contacts and stainless-steel locking provide dependable connection performance. Its high IP rating and hygienic construction make it suitable for food and beverage applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
EBT009 combines one M12 plug with two M12 sockets in a compact Y-shaped configuration. This allows multiple devices to be connected through a common connection point. The 5-pole design supports compatible automation signals. The configuration helps simplify machine wiring.
The splitter supports a logic OR function for compatible applications. This allows signals from the connected branches to be combined according to the device's electrical design. It can simplify certain sensor and control architectures. Correct electrical compatibility should be verified before installation.
EBT009 is silicone-free and uses gold-plated contacts. The housing is made from orange PA with EPDM sealing. Stainless-steel 316L locking components provide corrosion-resistant mechanical coupling. These materials are suitable for hygienic industrial environments.
The splitter provides IP65/IP67/IP68/IP69K protection. It is designed to withstand high-pressure cleaning and aggressive cleaning agents. Port identification is visually and tactually accessible. The mechanical end stop helps protect the O-ring from damage.
Y-splitter
1 × M12 plug
2 × M12 sockets
5-pole connection
Logic OR function
Gold-plated contacts
Silicone-free
EPDM sealing
Stainless-steel 316L locking
High-pressure cleaning resistant
IP65 / IP67 / IP68 / IP69K
Food and beverage industry
Hygienic automation
Sensor signal distribution
Machine automation
Compact wiring systems
Wet-area installations
Washdown machinery
Industrial control systems
| Specification | Details |
|---|---|
| Product Type | Y-Splitter |
| Model | ZDO2H050VAS0000-00STGH050VAS |
| Configuration | 1 × M12 Plug / 2 × M12 Sockets |
| Connector Coding | A |
| Contacts | 5 |
| Contact Finish | Gold-plated |
| Logic Function | OR |
| Operating Voltage | <60 V AC/DC |
| cULus Voltage | 30 V AC / 42 V DC |
| Protection Class | II |
| Max. Current per Port | 4 A |
| Total Current Load | 4 A |
| Housing | PA, orange |
| Nut Material | Stainless steel 316L |
| Sealing | EPDM |
| Ambient Temperature | -25°C to +100°C |
| cULus Ambient | Up to +65°C |
| Storage Temperature | -25°C to +55°C |
| Protection | IP65 / IP67 / IP68 / IP69K |
| Weight | 35.7 g |
| Standard | IEC 61076-2-101 |
| Pack Quantity | 1 pc |
