The IFM EBF012 is a compact M12-to-M8 Y-splitter designed for hygienic and wet-area automation applications. It provides a practical interface between an M12 connection and M8 field connections while maintaining reliable electrical performance. Gold-plated contacts, stainless-steel components and EPDM sealing provide durability in demanding environments. Its high protection rating makes it suitable for food processing and other industrial applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBF012 provides a convenient branching solution for applications requiring different connector formats. Its M12-to-M8 configuration allows compatible sensors and devices to be connected through a compact connection component. The small housing helps simplify installation in areas with limited space. It can be used as part of structured machine-level wiring systems.
Gold-plated contacts help provide stable electrical conductivity and dependable signal transmission. The connector is designed for low-voltage AC/DC industrial applications. Stainless-steel locking components provide secure mechanical connection during operation. This combination supports reliable connectivity for sensors and automation devices.
The EBF012 is free from silicone and uses a PA housing with EPDM sealing. Stainless-steel components provide additional mechanical durability in wet and hygienic environments. These materials are suitable for applications where regular cleaning and moisture exposure may occur. The construction supports reliable operation in food-industry installations.
The EBF012 provides IP65, IP67, IP68 and IP69K protection when connected correctly. It is designed for demanding industrial conditions with an ambient temperature range of -25 to 80 °C. The high ingress protection supports use in wet and washdown environments. This makes the splitter suitable for hygienic production and automation equipment.
M12-to-M8 Y-splitter configuration
Gold-plated contacts
Silicone-free construction
Halogen-free PA housing
Stainless-steel locking components
EPDM sealing
IP65, IP67, IP68 and IP69K protection
Compact installation design
Suitable for hygienic environments
Reliable low-voltage connection
Food processing machinery
Beverage production systems
Hygienic automation equipment
Sensor and actuator connections
Packaging machinery
Wet-area installations
Industrial machine control
| Specification | Details |
|---|---|
| Product Model | EBF012 |
| Order Code | ZDO2F030VAS0000-00STGH040VAS |
| Product Type | Y-Splitter |
| Connection Type | M12 to M8 |
| Operating Voltage | <50 V AC / <60 V DC |
| cULus Voltage | 30 V AC / 42 V DC |
| Protection Class | III |
| Contact Material | Gold-plated |
| Housing Material | PA, halogen-free |
| Locking Material | Stainless steel 316L / 1.4404 |
| Sealing Material | EPDM |
| Silicone Free | Yes |
| Cable Material | PUR, flame-retardant |
| Protection Rating | IP65, IP67, IP68, IP69K |
| Ambient Temperature | -25 to 80 °C |
| cULus Ambient Temperature | Up to 65 °C |
| Weight | Approx. 28.7 g |
| Plug Connection | 1 x M12 |
| Pack Quantity | 1 piece |
