The IFM EBC139 is a 10-port industrial splitter box designed for centralized sensor and actuator connectivity. It combines multiple M8 ports with a central M12 connection to simplify field wiring. The compact housing is resistant to oils and coolants and provides reliable sealing for industrial installations. Integrated LEDs make operating and switching conditions easy to monitor.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC139 provides 10 M8 ports for connecting multiple field devices through one centralized connection point. This arrangement helps reduce wiring complexity and provides a structured connection solution for automated machinery. It is suitable for applications requiring several sensors in a limited installation area.
The splitter box uses PBT-GF20 construction with nickel-plated brass components for reliable mechanical performance. The materials are designed for industrial environments where exposure to oils and coolants may occur. The compact housing also supports convenient installation in restricted spaces.
Gold-plated contacts provide dependable electrical connectivity and help minimize contact degradation. The central M12 interface provides a practical connection to the control system. This configuration supports stable sensor signal transmission in automated equipment.
Integrated yellow LEDs provide individual switching-status indication, while the green LED indicates operation. This visual feedback helps maintenance personnel quickly identify connection or operating conditions. The clear indication can reduce troubleshooting time during machine maintenance.
10-port M8 splitter box
Central M12 connection
PBT-GF20 housing
Nickel-plated brass components
Gold-plated contacts
IP67 and IP68 protection
10 yellow switching-status LEDs
1 green operation LED
Compact installation design
Oil and coolant resistant construction
Industrial automation systems
Machine sensor networks
Assembly and production machinery
Packaging equipment
Conveyor systems
Factory control systems
Automated material handling
| Specification | Details |
|---|---|
| Product Model | EBC139 |
| Order Code | ZDOAF03BMSS0000-STGH120MSS |
| Product Type | Splitter Box |
| Number of Ports | 10 |
| Connector Type | M8 |
| Central Connection | 1 x M12 |
| Housing Material | PBT-GF20 |
| Connection Material | Brass, nickel-plated |
| Contact Material | Gold-plated |
| Supply Voltage | Approx. 15–30 V DC |
| Output Type | PNP |
| Protection Rating | IP67, IP68 |
| Ambient Temperature | -25 to 80 °C |
| Moving Ambient Temperature | -5 to 60 °C |
| Weight | Approx. 150.5 g |
| Status Indication | 10 yellow LEDs |
| Operation Indication | 1 green LED |
| Pack Quantity | 1 piece |
