The IFM EBC138 is an 8-port splitter box designed to simplify sensor connectivity in industrial automation applications. It provides M8 ports with a central M12 connection and clearly visible LED indicators for operating and switching status. Its compact housing is suitable for installations where space is limited. The robust construction offers reliable protection against oils, coolants and demanding industrial conditions.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC138 provides a centralized connection point for multiple sensors and actuators. Its compact rectangular housing helps reduce wiring complexity and keeps machine-level connections organized. The design is particularly useful where installation space is restricted.
With eight M8 connection ports, the splitter box allows multiple field devices to be connected to a common control interface. The M12 connection provides a reliable link to the machine control system. Gold-plated contacts support dependable electrical signal transmission.
The housing uses PBT-GF20 material with nickel-plated brass connection components for improved mechanical strength and durability. The construction is resistant to oils and coolants commonly encountered around industrial machinery. This makes it suitable for manufacturing and automation environments.
Integrated LEDs provide clear indication of switching and operating status. The yellow LEDs allow individual port activity to be monitored, while the green LED indicates overall operation. This simplifies troubleshooting and maintenance during machine operation.
8-port M8 splitter box
Central M12 connection
PBT-GF20 housing
Nickel-plated brass components
Gold-plated contacts
IP67 and IP68 protection
8 yellow switching-status LEDs
1 green operation LED
Compact rectangular design
Oil and coolant resistant construction
Factory automation systems
Machine control systems
Sensor connection panels
Assembly machines
Packaging equipment
Material handling systems
Industrial production lines
| Specification | Details |
|---|---|
| Product Model | EBC138 |
| Order Code | ZDO8F039MSS0000-STGH120MSS |
| Product Type | Splitter Box |
| Number of Ports | 8 |
| Connector Type | M8 |
| Central Connection | 1 x M12 |
| Housing | Rectangular |
| Dimensions | Approx. 129.5 × 30 × 28.8 mm |
| Housing Material | PBT-GF20 |
| Connection Material | Brass, nickel-plated |
| Contact Material | Gold-plated |
| Supply Voltage | Approx. 15–30 V DC |
| Output Type | PNP |
| Protection Rating | IP67, IP68 |
| Ambient Temperature | -25 to 80 °C |
| Moving Ambient Temperature | -5 to 60 °C |
| Weight | Approx. 128.5 g |
| Status Indication | 8 yellow LEDs |
| Operation Indication | 1 green LED |
| Mounting | Backplane mounting |
| Pack Quantity | 1 piece |
