The IFM EBC137 is a compact 10-port splitter box designed for reliable sensor and actuator connections in industrial automation systems. It features M8 connections, gold-plated contacts, and a durable PBT-GF20 housing with nickel-plated brass components. The 10 m PUR cable provides flexible installation for fixed and dynamic applications. Its robust construction and high ingress protection make it suitable for demanding industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC137 features a compact splitter-box design that helps organize multiple sensor connections in limited installation spaces. Its PBT-GF20 construction provides mechanical durability, while the nickel-plated brass components support long-term reliability. The design is suitable for industrial control cabinets and machine installations where dependable connectivity is required.
The splitter box provides 10 M8 connection ports for connecting multiple sensors or actuators to a central connection point. Gold-plated contacts help provide stable electrical connections and improved resistance to contact degradation. The M12 connection provides a practical interface with the control system.
The EBC137 is supplied with a 10 m PUR cable designed for industrial installation requirements. Its cable construction supports flexible applications and can withstand repeated movement when installed according to the specified bending radius. This makes it suitable for machinery and automated equipment with moving components.
The splitter box provides IP65, IP67 and IP68 protection for reliable operation in industrial environments. It is designed for ambient temperatures from -25 to 80 °C, with defined limits for moving applications. The robust housing and protected connections help maintain dependable operation in challenging conditions.
10-port M8 splitter box
10 m PUR halogen-free cable
Gold-plated contacts
PBT-GF20 housing construction
Nickel-plated brass connection components
IP65, IP67 and IP68 protection
Visible yellow switching-status LEDs
Green operation LED
Suitable for dynamic cable applications
Reliable multi-sensor connection
Industrial automation systems
Machine automation and control panels
Sensor and actuator connection
Conveyor and material handling systems
Packaging machinery
Production and assembly equipment
Robotic and automated machinery
| Specification | Details |
|---|---|
| Product Model | EBC137 |
| Order Code | ZDOAF03BMSS0010H12 |
| Product Type | Splitter Box |
| Number of Ports | 10 |
| Connector Type | M8 |
| Connection | 1 x M8 socket, 1 x M12 connection |
| Cable Length | 10 m |
| Cable Material | PUR |
| Cable Diameter | 9.1 mm |
| Conductor Configuration | 10 x 0.34 mm² + 2 x 0.75 mm² |
| Housing Material | PBT-GF20 |
| Connection Material | Brass, nickel-plated |
| Contact Material | Gold-plated |
| Protection Rating | IP65, IP67, IP68 |
| Ambient Temperature | -25 to 80 °C |
| Moving Ambient Temperature | -5 to 60 °C |
| Weight | Approx. 969.5 g |
| Status Indication | 10 yellow LEDs |
| Operation Indication | 1 green LED |
| Pack Quantity | 1 piece |
