The IFM EBC060 is a compact four-way splitter box designed for reliable connection of sensors and actuators in industrial automation systems. It features four M8 connection ports and an M12 quick-disconnect connection. The NPN electrical design supports 10...30 V DC operation for compatible automation applications. Its robust housing, gold-plated contacts and LED indicators provide dependable performance in industrial environments.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC060 provides four M8 connection points in a compact wiring block designed for industrial sensor and actuator applications. It allows multiple field devices to be connected through a centralized connection point. This arrangement helps reduce wiring complexity and keeps machine installations organized. Its compact construction is especially useful where installation space is limited.
The splitter box uses an NPN electrical design and operates within a 10...30 V DC supply range. It provides a reliable interface between compatible sensors, actuators and control equipment. Gold-plated contacts support stable electrical transmission and dependable connection performance. The M8 connection system allows convenient integration with compatible industrial components.
The EBC060 uses an M12 connector for the main electrical connection, providing a secure and standardized interface. The quick-disconnect arrangement simplifies installation and maintenance activities. It allows technicians to establish or remove connections efficiently during machine servicing. This makes the splitter box suitable for production and automation equipment.
The housing combines PBT-GF20 and nickel-plated brass components for durability in industrial environments. IP65, IP67 and IP68 protection helps protect the connection system against dust and water exposure. Four yellow LEDs indicate switching status while a green LED indicates operating status. These visual indicators support easier commissioning and troubleshooting.
4-way splitter box
4 M8 connection ports
NPN electrical design
10...30 V DC operating voltage
M12 quick-disconnect connection
Gold-plated contacts
PBT-GF20 housing
Nickel-plated brass components
IP65/IP67/IP68 protection
4 yellow switching LEDs
1 green power LED
Compact construction
Oil and coolant resistant
Industrial automation systems
Factory automation machinery
Machine tools
Sensor and actuator connection
Production equipment
Assembly machinery
Control panel and field wiring
Compact machine installations
| Specification | Details |
|---|---|
| Product Code | EBC060 |
| Model | ZDO4F035MSJ0000---STGH080MSJ |
| Product Type | Splitter Box / Wiring Block |
| Electrical Design | DC NPN |
| Number of Ports | 4 |
| Port Connector | M8 |
| Main Connection | M12 connector |
| Connection Type | Quick disconnect |
| Operating Voltage | 10...30 V DC |
| Maximum Current per Port | 2 A |
| Maximum Total Current | 2 A |
| Protection Class | III |
| Protection Rating | IP65 / IP67 / IP68 |
| Housing Material | PBT-GF20 |
| Connector Material | Brass, nickel-plated |
| Contacts | Gold-plated |
| Ambient Temperature | -25...80 °C |
| Moving Temperature | -5...60 °C |
| Switching Indication | 4 × yellow LED |
| Power Indication | 1 × green LED |
| Mounting | Backplane / suitable machine mounting |
| Optional Accessories | DIN rail adapter E73006 |
| Protective Accessory | M8 protective cap E73005 |
| Pack Quantity | 1 piece |
