The IFM EBC058 is a compact four-port NPN splitter box designed for reliable sensor and actuator connectivity. It features four M8 ports and a 5 m PUR cable for flexible industrial installation. The PBT-GF20 housing provides IP65, IP67 and IP68 protection. Gold-plated contacts, LED indicators and drag-chain suitability support reliable performance in dynamic automation applications.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC058 provides four M8 connection ports for connecting sensors and actuators through a centralized field connection. Its compact construction makes it suitable for restricted installation spaces. The NPN electrical design supports compatible industrial automation circuits. Centralized wiring also helps simplify machine installation and maintenance.
The splitter box operates from a 10...30 V DC supply and provides dependable electrical signal distribution. A-coded M8 connectors allow convenient connection of compatible field devices. Gold-plated contacts support reliable electrical performance over repeated industrial operation. The design is suitable for automation machinery and production equipment.
The EBC058 includes a 5 m PUR cable for flexible connection to the control system. The halogen-free cable construction is suitable for industrial installations. It is designed to support moving-machine applications and drag-chain use under specified conditions. Maintaining the correct bending radius helps prevent unnecessary cable stress.
The PBT-GF20 housing with nickel-plated brass components provides a durable enclosure. IP65, IP67 and IP68 protection helps protect the connection system against dust and moisture. Four yellow LEDs indicate switching status and one green LED indicates operation. This makes the unit easier to commission and troubleshoot.
4 M8 ports
NPN electrical design
10...30 V DC operation
5 m PUR cable
2 A maximum current per port
6 A maximum total current
IP65/IP67/IP68 protection
PBT-GF20 housing
Gold-plated contacts
4 yellow LEDs
1 green LED
Drag-chain suitable
Halogen-free cable
Industrial automation
Factory automation
Machine tools
Production machinery
Sensor connections
Actuator connections
Moving machine applications
Space-restricted automation equipment
| Specification | Details |
|---|---|
| Product Code | EBC058 |
| Model | ZDO4F035MSJ0005H10 |
| Product Type | Splitter Box |
| Electrical Design | NPN |
| Number of Ports | 4 |
| Connector Type | M8 |
| Connector Coding | A-coded |
| Operating Voltage | 10...30 V DC |
| Maximum Current per Port | 2 A |
| Maximum Total Current | 6 A |
| Protection Class | III |
| Protection Rating | IP65 / IP67 / IP68 |
| Housing Material | PBT-GF20 |
| Connector Material | Brass, nickel-plated |
| Weight | Approx. 368.5 g |
| Cable Length | 5 m |
| Cable Material | PUR |
| Cable Diameter | Approx. 6.4 mm |
| Cable Cores | 4 × 0.34 mm² + 2 × 0.75 mm² |
| Cable Colour | Black |
| Cable Construction | Halogen-free |
| Contacts | Gold-plated |
| Mounting | Backplane mounting |
| Ambient Temperature | -25...80 °C |
| Moving Temperature | -5...60 °C |
| Flexible Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Drag-Chain Suitability | Yes |
| Switching Status | 4 × yellow LED |
| Operation Status | 1 × green LED |
| Accessories | DIN rail adapter E73006, M8 protective cap E73005 |
| Pack Quantity | 1 piece |
