The IFM EBC048 is a four-port PNP splitter box designed for compact sensor and actuator connectivity in industrial automation. It features four M8 ports and a 5 m PUR cable for flexible machine installation. The robust PBT-GF 20 and nickel-plated brass construction provides IP65, IP67 and IP68 protection. LED indication and gold-plated contacts support reliable operation and easy status monitoring.
Explore performance details, construction highlights, applications, and technical information in one clear overview.
The EBC048 provides four M8 ports for connecting compact industrial sensors and actuators. Its smaller M8 interface makes it suitable for applications where installation space is limited. Centralized field connections help simplify wiring and improve cable organization. The four-port configuration is suitable for compact automation equipment.
The splitter box uses PNP electrical technology and operates from 10...30 V DC. Each port supports up to 2 A, with a maximum total current of 6 A. This provides suitable power and signal distribution for connected sensors and actuators. The M8 connection system supports compact industrial installations.
The EBC048 includes a 5 m PUR cable that provides convenient connection distance for machine applications. The cable is halogen-free and designed for industrial use. It supports drag-chain installations and repeated movement under specified conditions. More than five million bending cycles are supported according to the product data.
The housing uses PBT-GF 20 and nickel-plated brass components for mechanical durability. IP65, IP67 and IP68 protection helps protect the splitter box in demanding environments. Four yellow LEDs provide switching-status indication while a green LED indicates operation. Gold-plated contacts support reliable electrical signal transmission.
4 M8 connection ports
PNP electrical design
10...30 V DC operation
5 m PUR cable
2 A maximum current per port
6 A maximum total current
IP65/IP67/IP68 protection
PBT-GF 20 housing
Nickel-plated brass components
4 yellow switching LEDs
1 green operation LED
Gold-plated contacts
Drag-chain suitable
More than 5 million bending cycles
Compact industrial automation
Factory automation
Machine tools
Sensor connection systems
Actuator connection systems
Production machinery
Space-constrained installations
Moving machine applications
| Specification | Details |
|---|---|
| Product Code | EBC048 |
| Model | ZDO4F035MSS0005H10 |
| Product Type | Splitter Box |
| Electrical Design | PNP |
| Number of Ports | 4 |
| Connector Type | M8 |
| Operating Voltage | 10...30 V DC |
| Protection Class | III |
| Maximum Current per Port | 2 A |
| Maximum Total Current | 6 A |
| Protection Rating | IP65 / IP67 / IP68 |
| Housing Material | PBT-GF 20 |
| Metal Material | Brass, nickel-plated |
| Cable Length | 5 m |
| Cable Material | PUR |
| Cable Diameter | 6.4 mm |
| Cable Colour | Black |
| Cable Cores | 4 × 0.34 mm² + 2 × 0.75 mm² |
| Cable Construction | Halogen-free |
| Contacts | Gold-plated |
| Dimensions | Product-specific compact housing |
| Weight | 367 g |
| Flexible Bending Radius | Min. 10 × cable diameter |
| Travel Speed | Max. 3.3 m/s under specified conditions |
| Maximum Acceleration | 5 m/s² |
| Bending Cycles | >5 million |
| Torsional Strain | ±180°/m |
| Drag-Chain Suitability | Yes |
| Switching Status | 4 × yellow LED |
| Operation Status | 1 × green LED |
| Optional Protective Cap | M8, E73005 |
| Optional DIN Rail Adapter | E73006 |
| Pack Quantity | 1 piece |
